WOODWARD 8440-2082 Grid connected generator set controller

WOODWARD 8440-2082 Grid connected generator set controller

Specific Parameters

Device Type Grid-connected Genset Controller

Product Series EasyGen 3000XT Series (EasyGen-3200XT-P1)

Power Supply 12/24VDC (8 to 40VDC)

Input Voltage 220V

Output Frequency 30kHz

Max. Power Consumption per Path < 0.15W

Power Setting Range 0.5–99999.9kW/kvar

Operating Temperature Range -20℃ to 70℃

Maximum External Discrete Inputs/Outputs 32

External Analog Inputs 16

External Analog Outputs 4

Communication Interface 1×RS485, 1×CAN Bus, Optional Ethernet Interface

Communication Protocol Supports Modbus RTU, Modbus TCP, CANopen Protocol

Housing Type Plastic Housing

Weight Approximately 1.81kg (4lbs)

Power Measurement Accuracy Class I

Mounting Type Panel Mount/Back Panel Mount

Certification Standards CE, UL, CSA, RoHS

Product Performance

Control Performance: It has complete engine-generator control and protection functions, can realize automatic grid connection, emergency power generation, standby power management, supports load transfer, soft loading/unloading, peak shaving and import-export control, can optimize energy use efficiency, and adapts to various power generation operation modes.

Communication Performance: Equipped with standard RS485 and CAN bus interfaces, optional Ethernet interface, supports communication protocols such as Modbus RTU, Modbus TCP and CANopen, can achieve stable data interaction with PLC, SCADA system, HMI and third-party equipment, and supports remote monitoring and control.

Expansion Performance: Adopts a modular design, which can be customized and expanded according to application needs. Through the CANopen protocol, it can connect up to 16 external analog inputs and 4 external analog outputs, has multi-interface toolkit connectivity, and strong function expandability.

Display Performance: Equipped with a display screen that can intuitively show the equipment operating status, alarm information and various operating parameters, with convenient operation, which is easy for on-site staff to view and troubleshoot faults.

Adaptability Performance: It has a drop-in replacement function, which can directly replace the previous generation EasyGen 3000 series controllers, and can be put into use without large-scale transformation, compatible with various generator sets, and adapts to various scenarios such as standby power, prime power and cogeneration.

Safety and Stability Performance: The internal power supply system is isolated, adopts high-quality materials and manufacturing processes, operates safely and stably, has complete fault protection functions, can effectively avoid equipment damage, and ensure the stable operation of the power generation system.

Environmental Adaptability Performance: It can operate stably in the temperature range of -20℃ to 70℃, has strong anti-interference ability, can withstand harsh working conditions on industrial sites, and meets the use needs of outdoor and complex industrial environments.
