WOODWARD 8440-1614 Industrial Human Machine Interface (HMI)
Specific Parameters
Device Type Industrial Human Machine Interface (HMI)
Product Series Woodward HMI Series
Power Supply Voltage 24VDC
Voltage Tolerance 18V to 30VDC
Rated Current Max. 1.6A
Power Consumption Typical 8W
Operating Temperature Range -20℃ to 60℃
Storage Temperature Range -30℃ to 70℃
Relative Humidity 5%-95% RH (Non-condensing)
Protection Level IP66 (Front)
Display Type TFT LCD
Display Resolution 800×480 Pixels
Touch Technology Resistive Touch
Dimensions (L×W×H) 230mm×190mm×55mm
Weight Approximately 0.8kg
Communication Interface Ethernet, RS-232, RS-485, USB
Mounting Type Panel Mount with Clip Lock
Cooling System Passive Cooling
Data Storage SD Card Slot for Data Logging
LED Indicators Status LEDs for Power and Operation
Material Aluminum Front Bezel, Polycarbonate Back Panel
Surface Finish Matte
Processor Frequency 60MHz
Certification Standards CE, UL, CUL, RoHS
Product Performance
Display Performance: Adopts TFT LCD display with 800×480 pixel resolution, equipped with LED backlight and resistive touch technology, with clear display and sensitive operation, which can real-time present equipment operation data and status, supporting stable display 24/7.
Communication Performance: Supports multiple communication interfaces including Ethernet, RS-232, RS-485 and USB, compatible with multi-protocols, can be seamlessly connected with programmable automation controllers, realizing real-time data transmission, remote configuration and debugging, with stable and reliable data transmission.
Protection Performance: The front protection level reaches IP66, which can effectively resist external interference such as dust and water splashes. The aluminum front panel and polycarbonate back panel are solid in material, with matte surface treatment and UV resistance, ensuring long service life.
Environmental Adaptability Performance: It can operate stably in a wide temperature range of -20℃ to 60℃, the storage temperature covers -30℃ to 70℃, can withstand 5%-95% non-condensing humidity environment, adopts passive cooling design, no additional cooling equipment is needed, adapting to harsh industrial scenarios.
Operation Performance: Compatible with Woodward Toolkit and CODESYS software, with a user-friendly operation interface, data logging and export can be realized through SD card slot, equipped with LED indicators for power and operation status, facilitating staff to quickly judge the equipment operation status.
Structural Performance: With dimensions of 230mm×190mm×55mm and a weight of approximately 0.8kg, it adopts clip lock panel mounting method, easy to install, compact structure, saving equipment installation space, and adapting to various industrial control cabinets.
