YOKOGAWA VC401-10 Coupling unit module

YOKOGAWA VC401-10 Coupling unit module

Specific Parameters​

Core and Signal Parameters​

Module Type Industrial-grade modular coupler unit​

Series μXL Series Distributed Control System (DCS)​

Number of Input Channels 16​

Number of Communication Ports 10​

Supported Signal Types Analog (4-20mA, 0-10V), Digital (switch signal)​

Voltage Measurement Range 0-60V​

Current Measurement Range 0-20A​

Resistance Measurement Range 0-20MΩ​

Frequency Measurement Range 0-10kHz​

Output Frequency 100kHz​

Measurement Accuracy ±0.1%FS​

Resolution 0.1%​

Input Impedance 10kΩ​

Sampling Rate 100ms​

Electrical and Communication Parameters​

Power Supply Voltage 24VDC​

Communication Interfaces RS-232, RS-485, Ethernet​

Communication Protocols Vnet, Modbus, Profibus​

Data Transfer Rate 100Mbps​

Protection Functions Signal filtering, anti-interference circuit​

Overall Dimensions 100mm×68mm×26mm​

Weight 177g​

Environmental and Reliability Parameters​

Operating Temperature Range -20°C to +70°C​

Storage Temperature Range -40°C to +85°C​

Protection Class IP65​

Certification Standards CE, UL, RoHS, CSA​

Warranty Period 12 months​

Product Performance​

Strong signal adaptability, compatible with multiple types of analog and digital signals, covering complex industrial measurement and control needs​

High communication efficiency, 100Mbps transmission rate combined with multi-protocol support enabling millisecond-level data interaction​

Excellent measurement accuracy, ±0.1%FS accuracy and wide-range measurement ensuring the accuracy of signal acquisition​

Strong environmental tolerance, IP65 protection class and wide temperature operating range resisting dust, humidity and temperature fluctuations​

Outstanding anti-interference capability, built-in filtering circuit and shielding design reducing electromagnetic interference in industrial sites​

Good system compatibility, seamlessly connecting with μXL Series DCS and supporting linkage with multi-brand field devices​

Convenient installation and integration, modular structure and standardized interfaces simplifying cabinet layout and commissioning process​

High operational stability, supported by industrial-grade circuit design and multiple certifications meeting continuous production needs​
