WOODWARD 8200-1310 controller module
Specific Parameters
Brand WOODWARD
Product Series WOODWARD 505D Series (Next-Generation 505 Digital Control Series)
Product Type Digital Governor, Steam Turbine Controller, Integrated Graphic HMI Panel, Industrial Control Equipment, Original Spare Part
Model WOODWARD 8200-1310
Country of Origin USA (Produced by WOODWARD original factory)
Compatible Devices WOODWARD VariStroke Actuators, DSLC-II Power Management Networks, Steam Turbine Systems, Plant DCS Systems
Supply Voltage 24VDC
Input Type Digital Input, Analog Input
Output Type Relay Output, SSR Output
Communication Protocols Supports Modbus, Ethernet/IP, CANOpen Protocols
Operating Temperature Range -20℃ to +70℃
Storage Temperature Range -40℃ to 85℃
Relative Humidity 5% to 95%, Non-Condensing
Protection Class Complies with IP54 Protection Requirements
Applicable Areas Non-Hazardous Areas, Class I, Div.2, Groups A/B/C/D Areas
Control Functions Speed/Load Control, Acceleration PID Control, Critical Speed Avoidance, Reverse Rotation Sensing and Alarm
HMI Functions Integrated Graphic Panel, Multi-Language Display, Real-Time Trend Viewing, Graphic Steam Diagram, Configurable Tag Names
Special Functions Built-in Turbine Simulator, High-Speed Data Logging, OptiTune Adaptive PID Technology, Password-Enabled Logins
Communication Interfaces Ethernet Interface, Service Port, CANOpen Interface
Expansion Functions Supports Distributed I/O (LinkNet-HT) Expansion
Programming Method Supports Control Assistant Service Tool for Configuration, Saving, Comparing Parameters and Data Logs
Remote Control Supports RemoteView Program for Remote Monitoring and Control
Physical Dimensions Conforms to WOODWARD 505D Series Standard Dimensions
Physical Weight Conforms to WOODWARD 505D Series Standard Weight
Product Material Industrial-Grade Flame-Retardant Circuit Board, Waterproof, Dustproof and Shockproof Housing
Customizable No
Certification Standards Complies with ATEX/IECEx, CE Certification Standards
Warranty Period 12 Months
Product Performance
WOODWARD 8200-1310 is an original WOODWARD device with strong adaptability. It can be seamlessly integrated into various steam turbine systems and WOODWARD related control equipment, with convenient installation, supports on-site programming and offline training, and can stably realize precise control of steam turbine speed and load.
Integrated graphic HMI panel supports multi-language operation, with an intuitive interface, which can real-time view operating parameters, trends and fault information. Equipped with high-speed data logging function, it can accurately monitor turbine operating status and stress, facilitating maintenance personnel to quickly troubleshoot faults.
Equipped with OptiTune adaptive PID technology and advanced load suppression algorithm, it has 3 critical speed avoidance bands. The acceleration PID can limit overshoot to ensure stable plant start-up, with high control accuracy and strong operational stability.
It has rich communication interfaces, supports multiple protocols and remote control, can expand distributed I/O, adopts industrial-grade waterproof, dustproof and shockproof packaging, has strong wide temperature adaptability, can operate stably in harsh industrial environments and designated hazardous areas for a long time, and has low operation and maintenance costs.
