WOODWARD 5466-1035 Power equipment control module
Specific Parameters
Electrical Parameters
Power Supply Voltage: 24V DC (±15% wide-voltage input), supporting 12V DC emergency power supply modeControl Accuracy: Speed control accuracy ±0.2%, fuel quantity control accuracy ±0.5%Input Signals: 2 channels of 0-10V DC analog input (speed feedback, load signal), 8 channels of 24V DC discrete input (fault interlock, start-stop signal)Output Signals: 2 channels of 4-20mA current output (fuel actuator drive), 1 channel of PWM pulse output (auxiliary regulation, frequency 1-100Hz, duty cycle 0-100% adjustable)Communication Protocols: Compatible with Modbus RTU (RS485) and CANopen protocols, baud rate adjustable from 1200bps to 115.2kbpsDiagnostic Functions: Built-in overvoltage, overcurrent and sensor fault detection, supporting fault code storage (up to 100 historical faults)Redundancy Design: Dual redundancy for power supply and core control circuit, fault switching time ＜10msPower Consumption: Power consumption ≤15W under rated load, standby power consumption ≤5WStatus Indication: 4-digit LED digital tube (displaying speed and fuel quantity parameters), 3 status LEDs (power, operation, fault)
Environmental Parameters
Operating Temperature: -40℃ to +85℃ (non-condensing environment, compliant with IEC 60068-2-1/2 standard)Storage Temperature: -55℃ to +100℃Relative Humidity: 5% to 95% (non-condensing, compliant with IEC 60068-2-3 standard)Protection Rating: IP54 (module itself, dustproof and splashproof)EMC Compliance: Compliant with EN 55022 Class B (electromagnetic radiation) and EN 55024 (immunity) standards, common-mode interference immunity ≥120dBVibration Resistance: 10-2000Hz frequency range, 2g acceleration (sine wave), 1 hour of continuous testing per axisShock Resistance: 50g acceleration (11ms duration, compliant with IEC 60068-2-27 standard)
Mechanical Parameters
Overall Dimensions: 180mm (L) × 120mm (W) × 60mm (H)Housing Material: Die-cast aluminum alloy housing (surface anodized), with RFI shielding functionWeight: Approximately 1.2kgMounting Method: 35mm standard DIN rail mounting, or panel fixing via M4 screws (mounting hole spacing 160mm)Wiring Method: 2 sets of 16-pin pluggable terminal blocks (power, signal), supporting wire diameter 0.5-2.5mm² (single/multi-strand copper wires)Certification Standards: UL 508 certification, CE certification, ATEX Zone 2 explosion-proof certification
Product Performance
Control accuracy is excellent: Speed control accuracy reaches ±0.2%, which can accurately suppress speed deviation caused by load fluctuations of power equipment; fuel quantity control accuracy is ±0.5%, ensuring fuel combustion efficiency and reducing energy consumption and emissions.
Redundancy reliability is high: Dual power supply and core circuit redundancy design, with fault switching time ＜10ms. Combined with comprehensive fault diagnosis functions, it can quickly locate sensor faults and actuator abnormalities, avoiding power system shutdown caused by single-point faults.
Communication compatibility is wide: Supports Modbus RTU and CANopen mainstream industrial protocols, and can be seamlessly connected to PLC, DCS and HMI systems to realize remote monitoring and parameter debugging of power equipment without additional protocol conversion modules.
Environmental adaptability is strong: The wide temperature range of -40℃ to +85℃ covers extremely cold and high-temperature scenarios; IP54 protection rating can be directly deployed outdoors or in dusty power machine rooms; anti-vibration and anti-electromagnetic interference design ensures stable operation in ship 颠簸 and industrial high-voltage environments.
Configuration flexibility is high: Supports software-customized control logic (such as load distribution algorithms, fault interlock conditions), adapts to internal combustion engines and gas turbines of different power levels from 100kW to 10MW, and can meet the control needs of diverse power equipment without replacing hardware.
