VIBRO-METER VM600 204-040-100-012 System rack configuration card

VIBRO-METER VM600 204-040-100-012 System rack configuration card

Specific Parameters​

Acquisition and Processing Parameters​

Module Type System rack configuration card (with data acquisition function)​

Channel Configuration 16 dynamic channels, 4 speed channels​

Input Signal Types Vibration, speed, temperature, phase reference signals​

Data Acquisition Accuracy 24-bit resolution, 80-bit floating-point operation accuracy​

Sampling Modes Asynchronous (fixed frequency), synchronous (sequential tracking) dual modes​

Signal Processing Capacity Up to 20 processing outputs per dynamic channel, 12 processing outputs per XMC16 module​

FFT Specification Maximum 6400-line resolution, one FFT operation per 500ms​

Vibration Measurement Range 0~50mm/s​

Temperature Measurement Range -50℃~+150℃​

Communication Interface RS485 (supports Modbus protocol)​

Rack and Electrical Parameters​

Compatible Systems ABE040, ABE042, VM600 Mk2 machinery monitoring systems​

Installation Capacity Accommodates up to 12 processing cards, supports power check relay installation​

Power Support Compatible with 2 RPS6U rack power supplies, supports AC/DC input and power redundancy​

Power Supply 24V DC​

Housing Structure Robust aluminum rack-mounted structure​

Operating Temperature -20℃~+70℃​

Humidity Range 0~95%RH (non-condensing)​

Protection Versions Available in standard, stand-alone circuit (IEC 60255-5), cCSAus certified (IEC 61010-1), conformal coating versions​

Software Compatibility Requires VibroSight monitoring software for operation​

Function Parameters​

Control Functions Integrates intelligent motion transformation technology, efficient tool management system​

Isolation Feature Electrical isolation between control circuit and main circuit​

Response Speed Relay output response time ≤10ms​

Status Monitoring Supports module health self-test and channel fault diagnosis​

Expansion Capacity Supports multi-rack cascading expansion​

Product Performance​

Excellent acquisition accuracy, 24-bit ADC + 80-bit floating-point operation, achieving nanometer-level measurement control​

High channel integration, 20 composite channels for synchronous acquisition, meeting multi-parameter monitoring needs​

Outstanding processing efficiency, 6400-line FFT high-speed operation, ensuring accurate extraction of fault features​

Strong system compatibility, adapting to multiple series of monitoring systems, supporting flexible expansion of 12 modules​

High operational reliability, dual power redundancy design, withstanding wide temperature and humidity industrial environments​

Fast control response, relays switching circuits quickly to ensure real-time control effect​

Excellent energy efficiency, low conduction voltage drop, reducing system energy consumption​

Low maintenance cost, long-life component design + fault self-test, reducing operation and maintenance investment​
