VARIAN 100010077-06 DC speed regulator control board

Specific Parameters

Brand VARIAN (American Brand)

Product Series Varian Industrial-Grade Speed Control Board Series

Product Type DC Speed Regulator Control Board

Model 100010077-06

Core Technology Pulse Width Modulation (PWM) Speed Regulation Technology

Operating Voltage Compatible with industrial DC power supply, supporting 12-24VDC wide voltage range

Speed Regulation Range 0-3000 rpm

Control Accuracy ±1 rpm

Response Time ≤50ms

Operating Temperature Range -20℃ to +60℃

Storage Temperature Range -40℃ to +85℃

Protection Functions Overcurrent protection, overvoltage protection, overheating protection

Installation Method Embedded installation, compatible with standard PCB board interface

Physical Dimensions 85mm×55mm×12mm

Physical Weight Approximately 50g

Product Performance

Adopting PWM core speed regulation technology, it has a wide speed regulation range and high control accuracy, can accurately respond to speed adjustment commands, meet the motor speed requirements under different working conditions, and adapt to diverse scenarios from low-speed stable operation to high-speed precise regulation.

Integrated with complete power management and protection circuits, it can real-time monitor the circuit current, voltage and temperature status, trigger the protection mechanism immediately when abnormalities occur, quickly cut off the circuit, effectively avoid damage to the motor and control board, and improve the safety of system operation.

With a response time as short as 50ms, it can quickly capture the speed adjustment signal and complete the adjustment without lag, ensuring that the motor speed instantly adapts to working condition changes and guaranteeing the continuity and stability of equipment operation.

Supporting 12-24VDC wide voltage adaptation, the embedded installation design can be directly connected to standard PCB boards, with a compact structure and light weight, not occupying too much internal space of the equipment, adapting to the integration needs of various industrial control equipment.

The wide temperature operating range can cope with harsh industrial environments with high and low temperatures, realizing trouble-free long-term continuous operation. It has excellent anti-electromagnetic interference capability, can maintain stable speed regulation accuracy in complex signal environments, and does not require frequent maintenance.
