TRICONEX 9566-8XX Redundant digital input module
Specific Parameters
Electrical Parameters
Operating Voltage 24VDC or 125VDC, supporting stable input of two specificationsInput Channels 32 independent digital input channels, mutually isolated between channelsInput Signal Types Dry contact signals, opto-isolated input signalsCommunication Protocols Compatible with Modbus TCP/IP and industrial Ethernet communication protocolsIsolation Level Electrical isolation between channels and between channels and system, isolation voltage 1500V ACProtection Features Built-in overvoltage protection, short circuit protection and reverse polarity protectionPower Consumption Maximum 15W, excellent energy consumption controlCertification Standards Compliant with IEC 61508 and SIL 3 safety standards
Mechanical Parameters
Overall Dimensions 160mm×100mm×60mm, compact structure suitable for rack mountingWeight Approximately 0.8kg, lightweight design facilitating deploymentMounting Method Rack mounting, compatible with TRICONEX standard control system racksHousing Material Industrial-grade high-strength alloy, with both anti-electromagnetic interference and mechanical protection performanceConnection Method Plug-in terminals, compatible with 0.5-2.5mm² shielded cablesProtection Rating IP20, suitable for indoor industrial control cabinet environmentsStatus Indication Equipped with power, operation and channel fault LED indicators to feedback working status in real time
Environmental Parameters
Operating Temperature -20℃ to 60℃, operation without derating over the entire temperature rangeStorage Temperature -40℃ to 85℃, meeting extreme storage and transportation requirementsRelative Humidity ≤95% (non-condensing), suitable for high-humidity industrial scenariosVibration Resistance Complies with IEC 60068-2-6 standard, withstanding conventional operation vibrationsShock Resistance Complies with IEC 60068-2-27 standard, withstanding 15g acceleration shockEMC Compliance Complies with EN 55014-1 and EN 55014-2 standards, with standard anti-external electromagnetic interference capability
Product Performance
Reliable redundant design: Adopts TMR triple modular redundancy architecture to avoid system operation impact from single point of failureExcellent safety level: Meets SIL 3 Safety Integrity Level requirements, adapting to safety-critical applicationsThorough channel isolation: 1500V AC electrical isolation design ensures pure and interference-free signalsStable signal collection: 32 independent channels support multi-device access with no packet loss in data transmissionFlexible communication integration: Compatible with mainstream industrial protocols, seamlessly connecting to TRICONEX and third-party control systemsComprehensive diagnostic functions: Real-time monitoring of channel status and module faults for quick problem locationStrong environmental adaptability: Wide temperature operation and strong anti-interference design tolerate complex working conditions such as dust and electromagnetic interferenceHigh operational reliability: Industrial-grade components and multiple protection mechanisms, Mean Time Between Failures (MTBF) ≥1,000,000 hours
