TRICONEX 4609 digital output module
Specific parameters
Counting function:
Counting mode: Supports 1-input mode (up, down) and 2-input mode (up/disable, up/reset, down/disable, down/reset, up/down, clock/direction).
Encoder mode: Supports encoder 1x, encoder 2x, and encoder 4x modes. In encoder 4x mode, the count rate can reach 62.5K, 100K, 125K, 250K, 500K, 1M, 2Mbps. In other modes, the count rate is 0-50KHz (except for 0-25KHz in encoder 4x mode).
Counter range: 32 bits wide/channel, maximum 30 bits.
Input/output type:
Input: 4 24 VDC inputs, RS422 differential inputs (D+, D -).
Output: 2 24 VDC outputs, 0.5 Amp, RS422 differential outputs (C+, C -).
Electrical characteristics:
Protection: Equipped with short-circuit protection function.
Leakage current in disconnected state: meets relevant standards.
Input filter: optional on/off.
Output preset: supported.
Internal power supply: 5VDC load, 160 mA @ 5.0 VDC maximum, 150 mA @ 5.0 VDC maximum.
Physical characteristics: The size is 99mm × 12mm × 70mm (H × W × D).
Product Performance
High precision counting: capable of accurately counting high-speed pulse signals with a wide counting range, meeting various high-precision counting requirements.
Multiple interface support: Provides multiple input and output interface types, including RS422 differential interface and 24 VDC interface, which can be easily connected to different types of encoders and other devices with strong compatibility.
Flexible counting mode: It has multiple counting modes and encoder modes, which can be flexibly configured according to actual application scenarios to meet different control requirements.
Reliable performance: Using high-quality electronic components and advanced circuit design, it has good stability and anti-interference ability, and can operate reliably in harsh industrial environments.
