TRICONEX 4509 Communication interface module
Specific Parameters
Brand TRICONEX (Original Authentic, a subsidiary of Schneider Electric), Product Series TRICONEX Safety Instrumented System (SIS) Series
Product Type Industrial-Grade Communication Interface Module, Original Authentic Spare Part
Model TRICONEX 4509
Country of Origin United States
Compatible Devices Tricon Series Safety Controllers, TRICON System Racks, Industrial Upper Computers, DCS Systems, SCADA Systems, Remote I/O, External Terminal Equipment
Core Functions Multi-protocol Communication, Real-Time Data Transmission, Remote Diagnosis, Port Isolation Protection, Communication Status Monitoring, Fault Self-Diagnosis, Hot Standby Ready, Alarm Synchronous Transmission
Product Structure Standard rack-mounted industrial module, compact design, front wiring and multi-status LED indicators, mechanical anti-misinsertion design
Communication Interfaces 2×10/100BaseT Ethernet interfaces (RJ45), 4×RS-232/RS-485 serial ports (DB-9 connectors)
Port Isolation 500VDC
Supported Protocols TriStation, Modbus RTU, Modbus TCP/IP, ICMP, SNTP, TSAA, Point-to-Point Time Synchronization Protocol
Communication Speed Ethernet 10/100 Mbps adaptive, Serial ports up to 115.2 Kbps
Safety Level SIL3 (Certified by TÜV Rheinland, Complies with IEC 61508 Standard)
Operating Voltage 24V DC (11VDC to 28.8VDC)
Maximum Power Consumption No more than 22W
Operating Temperature Range -40℃ to +70℃
Storage Temperature Range -40℃ to +85℃
Relative Humidity 5% to 95%, Non-Condensing
Protection Class IP20 (Complies with IEC 60529 Standard)
Mounting Method Tricon rack embedded installation, supporting online hot swapping, occupying a single slot
Dimensions 160mm×110mm×50mm (Height×Width×Depth)
Weight 1.2kg
Product Performance
Adaptability Performance: Fully compatible with Tricon series safety controllers and TRICON system racks, can seamlessly dock with DCS, SCADA systems and remote I/O, compatible with Tricon v9.0 and above systems, no additional adaptation required, high integration efficiency.
Communication Performance: Integrating dual Ethernet ports and multiple serial ports, supporting parallel communication of various industrial standard protocols, stable communication rate and low data transmission delay, which can transmit system variables and diagnostic information at full rate, with rapid alarm synchronous response.
Stability Performance: Adopting TMR triple modular redundancy architecture, made of industrial-grade components, with port isolation design, strong anti-electromagnetic interference and anti-radio frequency interference capabilities, safety level up to SIL3, can operate stably and continuously for a long time in harsh industrial environments, ensuring no interruption of communication links.
Operation and Maintenance Performance: Modular design, supporting online hot swapping, no need to shut down the machine during maintenance, multi-status LED indicators can intuitively feedback module operation status and fault information, fault self-diagnosis function can quickly troubleshoot communication and module faults, reducing downtime.
Structural Performance: Compact rack-mounted design, reasonable layout, mechanical anti-misinsertion design to prevent misinsertion, small space occupation in control cabinets, single-slot design facilitating combined installation with other I/O modules and controllers, adapting to high-density installation needs.
