TRICONEX 4000094-313 Safety relay module

TRICONEX 4000094-313 Safety relay module

Specific Parameters​

Electrical Parameters​

Operating Voltage: 24V DC, compatible with standard power supply for industrial safety circuits​

Input Voltage: Supports 220V AC wide-range input, adapting to different industrial power supply scenarios​

Power Consumption: Typical operating power consumption 5W, no additional power consumption increase under full load​

Safety Integrity Level: SIL 3 (compliant with IEC 61508), meeting safety-critical scenario requirements​

Communication Protocol: Compatible with Modbus protocol, enabling data interaction with control systems​

Insulation Resistance: ≥100MΩ between input and output (measured at 500V DC, normal temperature and state)​

Voltage Withstand Strength: ≥2500V AC between input and ground, no breakdown for 1 minute, leakage current ≤1mA​

Response Time: Signal processing and interlock action response ≤10ms, ensuring rapid protection​

Diagnostic Coverage: ≥99%, supporting open circuit, short circuit and internal module fault detection​

Mechanical Parameters​

Overall Dimensions: 140mm (L) × 55mm (W) × 130mm (D), compact module design​

Weight: Approximately 0.4kg, compatible with TRICONEX standard I/O rack installation​

Mounting Method: Plug-in installation, compatible with TRICON series safety system rack rails​

Housing Material: Flame-retardant engineering plastic, with chemical corrosion resistance and electromagnetic shielding properties​

Connection Method: Screw-type terminal block, compatible with ≤1.5mm² wires​

Protection Rating: IP20, suitable for dry environment inside control cabinets​

Status Indication: Module-level green LED (normal operation), red LED (fault alarm)​

Environmental Parameters​

Operating Temperature: -40℃ to 70℃, operation without derating​

Storage Temperature: -40℃ to 85℃, meeting extreme storage and transportation requirements​

Relative Humidity: 5% to 95% (non-condensing), suitable for high-humidity industrial scenarios​

Vibration Resistance: 10-500Hz frequency range, 1.5g acceleration (sine wave), no structural loosening​

Shock Resistance: 20g acceleration (half-sine wave, duration 11ms), ensuring mechanical stability​

EMC Compliance: Meets EN 55014-1 (emission limits), EN 55014-2 (immunity)​

Installation Altitude: Normal operation ≤2000m, power derating 10% for every 1000m increase above 2000m​

Product Performance​

High safety and reliability: TMR redundancy architecture can tolerate single-channel faults, with system fault-free operation probability up to 99.99%​

Fast fault response: Millisecond-level signal processing and interlock action, preventing the expansion of hazardous working conditions​

Comprehensive diagnostic capability: Full-link fault detection and alarm, fault location accuracy ≥99%​

Strong integration compatibility: Seamless connection with TRICON safety controllers, supporting data interaction with DCS systems​

Convenient installation and maintenance: Compact design adapts to high-density racks, supporting online hot-swapping replacement​

Excellent environmental adaptability: Wide temperature and vibration-resistant design, adapting to harsh working conditions such as chemical workshops and offshore platforms​

Strong operational stability: Industrial-grade components and low-power design, Mean Time Between Failures (MTBF) up to 800,000 hours​
