TRICONEX 4000093-316 Efficient power controller

TRICONEX 4000093-316 Efficient power controller

Specific Parameters​

Electrical Parameters​

Input Voltage: Compatible with industrial standard AC input, supporting wide voltage fluctuation​

Output Voltage: 12/15/24/36/48V DC optional, supporting -20% to +10% precision adjustment​

Rated Power: 125W under convection cooling (+50℃ environment), 125W under forced air cooling (+50℃ environment)​

Peak Power: 150W, duration 5 seconds, responding to instantaneous high-load demands​

Operating Voltage: 24V DC, compatible with safety system standard power supply circuits​

Conversion Efficiency: Up to 92%, meeting high-efficiency energy-saving requirements​

No-Load Power Consumption: <0.3W, compliant with ErP directive energy efficiency standards​

Safety Certifications: IEC/EN/UL 62368-1 safety certification, SIL 3 safety integrity level​

EMC Compliance: Meets Class B EMC limits, integrated internal Class B filter​

Output Ripple: ≤1% peak-to-peak, ensuring stable power supply for sensitive equipment​

Insulation Resistance: ≥100MΩ between input and output (measured at 500V DC)​

Voltage Withstand Strength: ≥2500V AC between input and output, no breakdown for 1 minute​

Mechanical Parameters​

Overall Dimensions: 50.8mm (L) ×76.2mm (W) ×29.5mm (D), compact package design​

Weight: Approximately 150g, suitable for installation in space-constrained control cabinets​

Mounting Method: Open-frame installation, compatible with standard DIN rail fixing​

Housing Material: Flame-retardant engineering plastic, with chemical corrosion resistance​

Connection Method: Screw-type terminal block, compatible with ≤1.5mm² wires​

Protection Rating: IP20, suitable for dry environment inside control cabinets​

Status Indication: Dual-color LEDs for power operation (green) and overload fault (red)​

Environmental Parameters​

Operating Temperature: -40℃ to +85℃, operation without derating​

Storage Temperature: -40℃ to +105℃, meeting extreme storage and transportation requirements​

Relative Humidity: 5% to 95% (non-condensing), suitable for high-humidity industrial scenarios​

Vibration Resistance: 10-500Hz frequency range, 1.5g acceleration (sine wave), no structural loosening​

Shock Resistance: 30g acceleration (half-sine wave, duration 11ms), ensuring mechanical stability​

Altitude Adaptation: Normal operation ≤2000m, power derating 10% for every 1000m increase above 2000m​

Product Performance​

Strong power supply stability: Wide-range output voltage regulation and low ripple design ensure the operation of sensitive equipment​

Flexible load adaptation: 150W peak power can handle instantaneous high loads, avoiding power-off shutdown​

Excellent energy efficiency: 92% high conversion efficiency and low no-load power consumption reduce operating energy consumption​

High safety compliance: Multiple international safety certifications and SIL 3 level, suitable for safety-critical scenarios​

Excellent installation convenience: Compact design and open frame, suitable for high-density control cabinet layout​

Outstanding anti-interference capability: Built-in Class B EMC filter, meeting EMC requirements without additional grounding​

Superior reliability: Industrial-grade component design, Mean Time Between Failures (MTBF) up to 790,000 hours (per MIL-HDBK-217F standard)​
