TRICONEX 2071H 7400313-100 data acquisition module
Specific Parameters
- Electrical Parameters
Supply Voltage: 24V DC, supporting 20-30V DC wide voltage input
Signal Processing: Compatible with 4-20mA analog signals and HART digital signals, HART signal amplitude ±0.5mA, frequency 1200Hz/2200Hz
Communication Interfaces: 1 Ethernet (802.3 standard), 2 RS-485 serial interfaces, supporting fiber optic communication expansion
Communication Protocols: Compatible with TCP/IP, Modbus, HART protocols, built-in 26 communication drivers
Isolation Level: Electrical isolation between signal channels and system bus, isolation voltage ≥1000V DC
Protection Functions: Channel short-circuit protection, power reverse connection protection, data encryption protection
Power Consumption: Normal operation power consumption <15W
- Environmental Parameters
Operating Temperature: -40°C to 75°C (non-condensing)
Storage Temperature: -40°C to 85°C
Relative Humidity: 5% to 95% (non-condensing)
EMC Immunity: Complies with EN 61326-1 industrial standard, ESD protection ±15kV (air discharge)
Certification Standards: IEC 61508 SIL 3 certification, Achilles Level 1 cyber security certification, ATEX Zone 2 explosion-proof certification
- Mechanical Parameters
Dimensions: 160mm (L) × 100mm (W) × 40mm (H)
Weight: Approximately 0.8kg
Mounting Method: Triconex standard chassis slot mounting, supporting hot swapping
Housing Material: Flame-retardant reinforced plastic (UL 94 V-0 grade)
Indicators: Power Status (PWR, green steady on), Communication Status (COM, green blinking), Fault Status (ERR, red steady on)
Product Performance
The module adopts a modular redundant architecture, supporting online replacement. During replacement, the system maintains signal acquisition continuity without data loss. HART signal transmission and 4-20mA safety signals are physically isolated, certified to have no mutual interference, ensuring independence and reliability of safety circuits and communication circuits.
The data acquisition response time is ≤5ms, and the HART command processing cycle is ≤10ms, enabling real-time synchronization of analog data and equipment diagnostic information. It integrates comprehensive self-diagnosis function with a fault diagnosis coverage rate of >99.9%, which can real-time detect abnormalities such as communication interruption, signal loss and module failure. Fault information is uploaded to the controller in real time via bus.
It has Achilles Level 1 cyber security protection, supporting user authentication, data encryption and access permission control to prevent unauthorized operations and data tampering. Adapting to 24/7 continuous production scenarios, the Mean Time Between Failures (MTBF) is ≥1,200,000 hours (25℃ environment), and it can be seamlessly integrated with Triconex TMR series controllers.
