TOSHIBA ARND-3119 A6 2N3A3119-B control module

Specific Parameters

Electrical Parameters
Supply Voltage: 24V DC ±5%, supporting 22-26V DC wide-range input
Input Signals: 4-channel analog input (0-10V DC/4-20mA), 8-channel digital input (dry contact)
Output Signals: 2-channel analog output (4-20mA), 4-channel digital output (relay contact, capacity 2A/250V AC)
Communication Interface: 1×RS485 (Modbus RTU protocol), data transmission rate 9600-115200bps adjustable
Isolation Level: 2.5kV AC between signal input and system (1 minute), 1.5kV AC between power supply and signal circuit (1 minute)
Power Consumption: ≤15W under normal operation, maximum power consumption ≤20W
Operating Frequency: 50/60Hz compatible, supporting 0-120Hz signal processing
Control Accuracy: Analog signal error ≤±0.2% FS, digital response delay ≤1ms
Environmental Parameters
Operating Temperature: -20°C to 85°C, continuous operation without condensation
Storage Temperature: -40°C to 100°C
Relative Humidity: 10% to 90% (non-condensing, stable operation at 40°C/85% humidity)
EMC Immunity: Complies with EN 61000-4-2/3/4 standards, ESD protection ±15kV contact discharge
Vibration Resistance: 10-500Hz, 1g acceleration (IEC 60068-2-6 standard)
Shock Resistance: 20g acceleration, 11ms duration (IEC 60068-2-27 standard)
Protection Class: IP20 (board-level protection, requiring equipment cabinet for use)
Mechanical Parameters
Dimensions: 220mm (L) × 160mm (W) × 30mm (H), compatible with standard equipment card slots
Mounting Method: On-board pin plug-in mounting, secured with fixing screws
Interface Type: Phoenix terminals (input/output), DB9 pin interface (communication)
Housing Material: Flame-retardant epoxy resin substrate, with tin-plated surface
Weight: Approximately 450g
Indicators: Power (PWR, green), running (RUN, green), fault (ERR, red), communication (COM, yellow)

Product Performance

The module adopts a dedicated 32-bit processing chip with an operation speed ≥100MIPS, enabling parallel processing of multi-channel signals. The analog sampling rate reaches 10kHz, which can accurately capture subtle changes in equipment operating parameters. Integrated with an adaptive filtering algorithm, it effectively suppresses electromagnetic interference in industrial sites and maintains signal stability even in 690V high-voltage inverter environments.

The fault diagnosis function can real-time monitor fault status such as power abnormality, communication interruption and signal over-limit, with fault response time ≤10ms. Fault information is actively reported through the communication interface, and at the same time triggers local indicator alarm. The module supports online parameter configuration and program upgrade, which can be maintained without disassembly, adapting to the non-stop maintenance needs of industrial equipment.

It is fully compatible with Toshiba MegaVert series inverters and third-party PLC systems, with data interaction delay ≤5ms, meeting the real-time control requirements of high-voltage frequency conversion systems. The mean time between failures (MTBF) is ≥500,000 hours, complying with industrial-grade long-life operation standards.
