Tektronix DPO3054 Digital Phosphor Oscilloscope, High-Performance Oscilloscope for Precise Testing
The Tektronix DPO3054 Digital Phosphor Oscilloscope is an advanced instrument designed for reliable testing in various industrial applications. Featuring a bandwidth of 500 MHz and a sample rate up to 1 GS/s, it delivers fast waveform capture rates up to 20,000 wfm/s, making it ideal for capturing transient events.
Bandwidth:500 MHz
Sampling Rate:2.5 GS/s
Channels:4
Memory Depth:14 Mpoint
Waveform Captures:Up to 200,000 wfms/sec
Display:9-inch SVGA Color Display
Interface:USB 2.0 Host and Device Ports, Ethernet Port, GPIB (optional)
The Tektronix DPO3054 Digital Phosphor Oscilloscope is an advanced tool designed for engineers and technicians to perform detailed signal analysis in real-time. It features a robust design with a 9-inch WVGA color display for clear visibility of waveforms. With a bandwidth of 500 MHz and a sample rate up to 2.5 GS/s, it ensures precise measurements of fast-changing signals. The oscilloscope supports 4 channels, allowing simultaneous observation of multiple signals. Its high waveform capture rate of 20,000 wfm/s captures transient events quickly, while vertical sensitivity ranges from 2 mV/div to 10 V/div, making it suitable for a wide range of voltage levels. Input impedance of 1 MΩ ±2% ensures minimal loading on tested circuits. Additionally, the maximum record length of 10 Mpoints enables extensive data storage for in-depth analysis.
