SWITCHING TR-500Q-P-F1 3503311-02 Switching power module

SWITCHING TR-500Q-P-F1 3503311-02 Switching power module

Specific Parameters​

Core and Function Parameters​

Product Type Industrial-grade Switching Power Supply Module​

Model TR-500Q-P-F1, Part Number 3503311-02​

Series TR-500Q Series​

Manufacturer Switching Power Inc. (some data marked XYZ Controls)​

Country of Origin USA​

Conversion Type AC to DC Converter​

Installation Method Surface Mount​

Housing Material Aluminum Alloy​

Cooling Method Forced Air Cooling via Fan​

Protection Functions Overload Protection, Over-voltage Protection, Short-circuit Protection, Over-temperature Protection​

Protection Rating IP67​

Certification Standard Complies with EN 61000-3-2 Standard​

Power Cord Length 1.5m​

Electrical Parameters​

Input Voltage Range 90-264VAC​

Input Frequency 50Hz to 60Hz​

Input Current 5A​

Output Voltage 24VDC​

Output Current 20A​

Power Factor Correction Range 90-264VAC​

Physical and Environmental Parameters​

Overall Dimensions 10cm×5cm×2cm​

Weight 1.7kg​

Operating Temperature Range -25℃ to +85℃​

Product Performance​

90-264VAC wide input range, adapting to power grid standards in different regions worldwide with strong compatibility​

Stable output of 24VDC voltage and 20A current, meeting high-power supply needs of industrial equipment​

Integrates four protection mechanisms, effectively resisting power fluctuations and faults to avoid equipment damage with high safety​

IP67 protection rating with aluminum alloy housing, dustproof, waterproof and corrosion-resistant, suitable for harsh industrial environments​

Forced air cooling design ensures stable operation within -25℃ to +85℃ wide temperature range with strong environmental adaptability​

Compact size of 10cm×5cm×2cm and surface-mount design save installation space for convenient deployment​

Complies with EN 61000-3-2 standard with excellent electromagnetic compatibility, avoiding interference to surrounding equipment​
