SEW DFP 8227241.12 - High-Performance Gear Motor

SEW DFP 8227241.12 – High-Performance Gear Motor

Specific Parameters

Brand SEW (SEW-EURODRIVE)

Product Series DFP Series

Product Type Profibus FMS/DP Communication Module, Frequency Converter Supporting Communication Component

Model DFP 8227241.12

Communication Protocol Profibus FMS/DP Protocol

Data Rate 12Mbit/s

Physical Interface 9-pin D-type Connector

Supply Voltage 24VDC

Operating Temperature Range 0℃ to 50℃

Storage Temperature Range -20℃ to 60℃

Relative Humidity 5% to 95%, Non-Condensing

Protection Level IP20

Packaging Form Modular Packaging

Mounting Method DIN Rail Mount

Compatible Equipment SEW MOVIDRIVE Series Frequency Converters and Various SEW Compatible Frequency Converters

Core Functions Frequency Converter Remote Control, Parameter Setting, Status Monitoring, Alarm Handling

Physical Dimensions 100mm×70mm×40mm (Length×Width×Height)

Physical Weight 0.5kg

Compatible Network Profibus Bus Network

Anti-Interference Level Industrial-Grade Electromagnetic Interference Resistance

Product Performance

Supports Profibus FMS/DP dual communication protocols, with a data transmission rate of up to 12Mbit/s, enabling high-speed data interaction between frequency converters and upper computers without delay or freeze, ensuring real-time transmission of control commands.

Adopts a standard 9-pin D-type physical interface, with standardized and highly versatile wiring, which can quickly connect to Profibus bus network, frequency converters and upper computers, reducing wiring difficulty and improving installation efficiency.

Specifically designed for SEW frequency converters, it has extremely strong compatibility, can seamlessly adapt to SEW MOVIDRIVE and other series of frequency converters, realizing plug-and-play without additional modification, greatly shortening the commissioning cycle.

It has complete remote control and monitoring functions, which can remotely set frequency converter parameters and control the start and stop of frequency converters through the upper computer, and at the same time, real-time feedback the operating status, current, voltage, frequency and alarm information of frequency converters, facilitating remote management and control by staff.

Adopts an industrial-grade modular design with a compact structure and a protection level of IP20, which can effectively prevent dust and foreign objects from entering, adapt to complex industrial on-site environments, and has high operational reliability.

It has excellent anti-electromagnetic interference performance, can resist electromagnetic interference in industrial fields, ensure stable communication signals, and avoid data loss or control failure caused by interference.

Adopts 24VDC standard power supply, with low power consumption and stable power supply, which can be compatible with conventional industrial on-site power supply systems, without the need to configure additional dedicated power supply, reducing use costs.

Supports multi-device networking, which can connect multiple SEW frequency converters to the same Profibus network, realizing centralized management and control of multiple devices, adapting to the management and control needs of large-scale industrial automated production lines.

Equipped with friendly configuration software, which is convenient for staff to perform parameter configuration and fault diagnosis, with simple operation, reducing maintenance difficulty and maintenance cost.
