Specific Parameters​

Electrical Parameters​

Input Voltage 380-480V AC (-10% to +10%), frequency 50/60Hz​

Control Voltage 24V DC (-15% to +25%), control current 1A​

Rated Output Current 22A, peak output current 32A​

Rated Power 22kW​

Output Voltage 0-600V AC, output frequency 0-600Hz​

Pulse Frequency Up to 60kHz​

Overload Capacity 4x peak overload, coping with high dynamic loads​

Communication Interface Integrated SERCOS optical fiber interface, supporting real-time motion bus​

Protection Functions Overload protection, overvoltage protection, overtemperature protection, short-circuit protection​

Motor Compatibility Automatic recognition of Schneider PacDrive series servo motors (e.g., SM/SH series)​

Mechanical and Environmental Parameters​

Overall Dimensions 626mm×209mm×296mm (L×W×H)​

Weight Approximately 6.3kg​

Housing Material High-strength engineering plastic, impact-resistant design​

Protection Rating IP65, suitable for harsh industrial environments with dust and moisture​

Mounting Method Wall-mounted installation, supporting integration in control cabinets​

Operating Temperature -40℃ to 85℃, no performance derating over the entire temperature range​

Storage Temperature -40℃ to 90℃, meeting extreme storage and transportation requirements​

Heat Dissipation Method Internal fan forced cooling, ensuring stable operation under high load​

EMC Compliance Complies with EN 61800-3, EN 55011 standards​

Product Performance​

Extremely high control precision, 22-bit resolution + 60kHz pulse frequency, achieving micrometer-level positioning​

Fast dynamic response, millisecond-level bus communication delay, quickly reaching set motion parameters​

Strong load adaptability, 32A peak current + 4x overload capacity, coping with transient high-load conditions​

Good function expandability, supporting multi-mode control of position, speed and torque, adapting to complex motion needs​

Excellent environmental tolerance, IP65 protection + (-40℃ to 85℃) wide-temperature operation, withstanding harsh industrial environments​

Strong system compatibility, automatic servo motor recognition, seamless linkage with PacDrive controllers​

High operation and maintenance convenience, integrated fault diagnosis function, supporting rapid commissioning and component replacement​

High operational reliability, multiple protection mechanisms + industrial-grade components, Mean Time Between Failures (MTBF) ≥1000000 hours​
