SCANLAB INTELLISCANDE14-1064NM Laser scanning system

SCANLAB INTELLISCANDE14-1064NM Laser scanning system

Specific Parameters​

Optical and Performance Parameters​

Laser Wavelength 1064nm, compatible with YAG laser, fiber laser and other light sources​

Scanning Speed Up to 10m/s, marking speed up to 2.0m/s (with f=160mm lens configuration)​

Scanning Angle Maximum 60°, typical optical scanning angle ±0.35rad​

Repeat Accuracy ±8µm, angular repeatability ＜2µrad (RMS)​

Positioning Error ±10µm, nonlinearity error ＜3.5mrad/44°​

Resolution Up to 14 bits, positioning resolution up to 18 bits (requires SL2-100 interface)​

Mirror Diameter 14mm, adapting to 14mm aperture optical configuration​

Spot Size 23µm (1064nm, f=160mm lens, M²=1.0 configuration)​

Image Field Size 95mm×95mm (1064nm, f=160mm lens configuration)​

Laser Power Tolerance 440W (1064nm wavelength, 100% duty cycle)​

Electrical and Communication Parameters​

Power Supply Voltage Optional 24VDC or 30VDC, maximum operating current 6A​

Control Interfaces Supports Ethernet, RS232, RS485, standard SL2-100, XY2-100 enhanced digital interfaces​

Communication Protocols Compatible with Modbus, Modbus/TCP, Bently Nevada proprietary protocols​

Control Modes Supports both analog signal and digital signal control modes​

Processing Chips Integrates high-speed Digital Signal Processor (DSP) and high-performance FPGA chip​

Diagnostic Functions Equipped with iDRIVE advanced diagnostic function, real-time capture of key status parameters​

Mechanical and Environmental Parameters​

Overall Dimensions 200mm×200mm×100mm, compact design fits narrow installation spaces​

Weight Approximately 2.5kg, lightweight structure facilitates integrated installation​

Cooling Methods Supports both air cooling and water cooling configurations, adapting to different power scenarios​

Mounting Method Supports standard bracket mounting, connectors configurable on beam entrance and exit sides​

Operating Temperature 5℃ to 40℃, no performance derating over the entire temperature range​

Storage Temperature -20℃ to 60℃, meeting extreme storage and transportation requirements​

Relative Humidity 10% to 90% (non-condensing), adapting to high-humidity industrial environments​

Product Performance​

High positioning accuracy, 18-bit resolution and ±8µm repeat accuracy ensure precision processing quality​

Fast scanning speed, 10m/s high-speed scanning with 0.15ms tracking error improves processing efficiency​

Strong compatibility, optimized for 1064nm wavelength, adapting to multiple laser sources and lenses​

Flexible control, supports dual-mode control and 3 adjustable parameter configurations for multi-scenario needs​

Excellent integration, multi-protocol communication interfaces enable seamless connection with industrial control systems and HMI​

Superior stability, digital encoder technology achieves low drift and low dither for reliable long-term operation​

Comprehensive diagnosis, real-time status monitoring and fault feedback simplify equipment maintenance​

Wide adaptability, supports air and water cooling switching, tolerating complex industrial working conditions​
