REXROTH VT-HNC100-1-23M-08-P-0 Digital axis control module

REXROTH VT-HNC100-1-23M-08-P-0 Digital axis control module

Specific Parameters

Brand REXROTH (Bosch Rexroth)

Product Series VT-HNC100 Series

Product Type Digital Axis Controller Module, Precision Motion Control Module

Model VT-HNC100-1-23M-08-P-0

Country of Origin Germany

Processor 16/32-bit MC 68376

Rated Power Supply Voltage 18VDC-36VDC

Switching Inputs 8/16/24 Channels (Optional)

Maximum Current per Channel 30mA

Analog Current Inputs 4 Channels, Input Range 4mA-20mA

Position Sensor Compatibility Incremental Sensor, SSI Sensor

Storage Specification 1MB Flash EPROM, 8KB EEPROM, 256KB RAM

Operating Temperature Range 0℃ to 50℃

Storage Temperature Range -40℃ to 85℃

Relative Humidity 5% to 95%, Non-Condensing

Physical Dimensions 180mm×120mm×40mm

Physical Weight 1.1kg

Core Functions Closed-Loop Control of Electrohydraulic/Electromechanical Drives, Position/Speed/Pressure Control

Mounting Method DIN Rail Mounting, Screw Mounting

Certification Standards CE

Warranty Period 12 Months

Product Performance

Adopting a 16/32-bit MC 68376 high-performance processor, it has fast operation speed and high control precision, which can realize high-precision closed-loop control of position, speed and pressure of electrohydraulic axes and electromechanical drive systems, adapting to multi-axis linkage control needs.

Supports 8/16/24 flexible switching inputs, with a maximum current of 30mA per channel, and is equipped with 4 channels of 4mA-20mA analog current inputs, which can flexibly access various sensors and actuators, adapting to different industrial control scenarios.

Compatible with incremental sensors and SSI sensors, it can accurately collect position signals with high feedback control precision, effectively ensuring the motion precision and production stability of industrial equipment.

Adopting a modular design with a regular structure, fault units can be quickly identified and replaced without overall disassembly of the equipment, which greatly reduces downtime and improves industrial production efficiency.

It has a wide power supply voltage range, supporting 18VDC-36VDC power supply, which can be seamlessly integrated into various industrial power supply systems without additional power supply conversion modules, with high integration convenience.

It has excellent anti-electromagnetic interference, anti-vibration and anti-shock performance, complies with industrial EMC standards, and can operate stably for a long time in harsh industrial environments with frequent interference and vibration without performance degradation.

Equipped with 1MB Flash EPROM, 8KB EEPROM and 256KB RAM, it has sufficient storage capacity to stably store control programs and operating data, avoid data loss, and ensure continuous and stable control logic.

The operating temperature range covers 0℃ to 50℃, and the storage temperature range reaches -40℃ to 85℃, with strong environmental adaptability, which can adapt to high and low temperature industrial scenarios and has a long service life.

Certified by CE, the product quality and safety performance meet global industrial control standards, and can be directly applied to various high-precision control scenarios without additional safety testing.

Adopting dual mounting methods of DIN rail and screw, it is convenient and flexible to install, and can be flexibly selected according to the on-site installation space, adapting to the installation needs of different equipment.
