Specific Parameters

• Electrical ParametersSupply Voltage: Three-phase 200/400V AC, allowable fluctuation range ±10%, 50/60HzRated Current: Continuous output current 50A, peak output current 100APower Rating: Suitable for 22-30kW servo motorsControl Modes: Position control, speed control, torque control, supporting on-line mode switchingCommunication Interfaces: Standard RS-485 (supports Modbus RTU), optional Profibus-DP interfaceProtection Functions: Overcurrent, overvoltage, undervoltage, overheating, motor overload and short-circuit protection; short-circuit symmetrical RMS rating 5kA RMSDetection Feedback: Supports incremental encoder (TTL/HTL) and absolute encoder signal inputDisplay Unit: 7-segment LED nixie tube, displaying speed, current, fault code and other parametersControl Signals: Analog input (0-10V/4-20mA), 8 digital inputs/outputs each
• Environmental ParametersOperating Temperature: -10°C to 60°C (non-condensing environment, no derating)Storage Temperature: -40°C to 85°CRelative Humidity: 5% to 95% (non-condensing, continuous operation for 168 hours at 90% humidity and 40°C without failure)Vibration Resistance: 10-500Hz frequency range, 1.0g acceleration (complies with IEC 60068-2-6 standard, 2 hours test for X/Y/Z axes each)Shock Resistance: 20g acceleration, 11ms duration (complies with IEC 60068-2-27 standard, half-sine shock waveform)Certification Standards: UL 508 industrial control equipment certification, CE (EMC and safety certification)
• Mechanical ParametersDimensions: 450mm (L) × 250mm (W) × 180mm (H) (including heat sink)Weight: Approximately 12kgMounting Method: Chassis mounting, compatible with standard industrial control cabinet railsHousing Material: Cold-rolled steel plate spraying (corrosion-resistant, protection class IP20)Heat Dissipation: Natural cooling + forced air cooling, built-in temperature-controlled fanIndicators: Power (green steady on = normal), Operation (green blinking = working), Fault (red steady on = abnormal), Communication (yellow blinking = normal)

Product Performance

High speed control precision: Adopting PI adaptive adjustment algorithm, speed fluctuation rate ≤±0.1%, enabling smooth speed regulation from 0.1rpm to rated speed, suitable for precision transmission scenarios. Accurate position positioning: Supports pulse/bus command control, positioning error ≤±0.01mm (with 17-bit encoder), meeting high-precision requirements of machine tools and robots.

Fast dynamic response: Torque response time ≤10ms when load changes suddenly, no overshoot, adaptable to working conditions with frequent start-stop and forward-reverse switching. Comprehensive protection mechanism: Fault detection response time ≤1ms, which can quickly cut off power output and lock fault status to avoid damage to motors and controllers.

Strong system compatibility: Supports direct communication with PLC and motion controllers, compatible with Reliance automation systems and third-party equipment; modular design facilitates function expansion and maintenance. Excellent reliability: Industrial-grade components and wide-temperature design ensure Mean Time Between Failures (MTBF) ≥1.0×10⁶ hours, adapting to harsh industrial environments with dust and vibration.
