Prosoft MVI56-PDPMV1 Main station communication module

Prosoft MVI56-PDPMV1 Main station communication module

Specific Parameters

Brand Prosoft (Prosoft Technology Inc.), Product Series Prosoft MVI56 Series

Product Type Industrial-Grade PROFIBUS DP-V1 Master Communication Module, PLC Expansion Communication Module, Industrial Control Communication Component, Prosoft Original Spare Part

Model Prosoft MVI56-PDPMV1

Country of Origin The United States (Produced by Prosoft original factory, authorized and developed by Rockwell Automation)

Compatible Devices Rockwell ControlLogix Series PLC, PROFIBUS DP Slave Devices, Inverters, Remote I/O, Valve Islands, Industrial Sensors, Actuators, Distributed Control Systems (DCS), Automated Production Line Equipment

Core Functions PROFIBUS DP-V1 Master (Class 1)/Slave Switching, Protocol Conversion, Real-Time Cyclic Communication, Acyclic Communication, Slave Management, Network Diagnosis, Data Caching, 1756 Backplane Data Exchange, PROFIDrive 3.1 Parameter Reading and Writing

Communication Protocols Supports PROFIBUS DP-V1 Protocol, Complies with IEC 61158 and EN 50170 Standards, Supports DP-V0 and DP-V1 Functions

Communication Interfaces 1 9-pin D-sub (DB-9F) Optically Isolated RS-485 Interface, 1 RS-232 CFG Configuration Port

Data Transmission Rate Auto-detection or Manual Configuration, 9.6Kbps to 12Mbps, Up to 12Mbps

Maximum Number of Slaves Up to 125 PROFIBUS Slaves, Expandable with Repeater

Data Exchange Capacity Supports Maximum 64KB I/O Data Exchange, Configurable 1536 Cyclic Bytes Input and 1536 Bytes Output Data, Asynchronously Exchanges Data with PLC CPU

Master Commands Supports DP-V1 Acyclic Communication (Class 1 or Class 2 Services) for Parameterization and Diagnosis, Supports Synchronization and Freeze Commands, Extended Diagnostic Data

Configuration Method Supports Graphical Configuration, Debugging and Diagnosis via ProSoft Configuration Builder (PCB) Software, GSD File Importable, with Ladder Logic Sample Files Attached

Power Supply Method Powered by PLC 1756 Backplane, No Independent Power Supply Required, 800mA Available Power Needed

Operating Temperature Range 0℃ to 60℃

Storage Temperature Range -40℃ to 85℃

Relative Humidity 5% to 95%, Non-Condensing

Protection Class IP20 (Needs to Be Installed in the Cabinet, Installation in IP54 Protection Class Cabinet Recommended)

Physical Specification Standard 1756 Single-Slot Module, Compatible with 1756 Backplane

Physical Weight Approximately 0.3kg

Mounting Method 1756 Backplane Slot Mounting, Compatible with Rockwell ControlLogix Standard PLC Rack, Supports Local or Remote Rack Installation

Diagnostic Function Equipped with LED Indicators for Power, Module Status, Network Communication, Master Token Holding, etc., Supports Software Diagnostic Tools, Fault Information Uploadable, Supports Slave Configuration Consistency CRC Check

Product Material Industrial-Grade Reinforced Flame-Retardant Plastic Enclosure, High-Temperature Resistant Insulation Material, Built-in Optocoupler Isolation Components

Customizable No

Certification Standards Complies with CE, CSA, UL508, ATEX Relevant Certification Standards, Suitable for Class I, Division 2, Groups A, B, C, D Hazardous Locations

Warranty Period 36 Months (Prosoft Original Factory Warranty, Free Unlimited Technical Support Provided)

Product Performance

Prosoft MVI56-PDPMV1 is an original Prosoft device with extremely strong adaptability, specially designed for Rockwell ControlLogix series PLCs, compatible with 1756 backplane, can be directly identified as a PLC input/output module, no additional adaptation components required, seamlessly integrated into Rockwell control systems, greatly reducing system integration complexity and effectively solving the problem of multi-brand equipment integration. The product has excellent communication performance, supports a maximum data transmission rate of 12Mbps, can realize real-time data interaction between PLC and PROFIBUS slave devices without obvious delay and packet loss, supports 125 slave management and maximum 64KB I/O data exchange, meets the industrial control needs of multiple devices and multiple parameters, and supports DP-V1 acyclic communication to complete parameterization and diagnosis functions, compatible with various PROFIBUS DP slave devices. The product has outstanding reliability, adopts industrial-grade high-quality components and optical isolation design, has excellent anti-electromagnetic interference ability, can operate continuously and stably in a wide temperature environment of 0℃ to 60℃ and harsh working conditions such as dust and strong electromagnetic interference, has passed a number of international certifications, complies with hazardous area installation standards, and the 3-year original factory warranty and free technical support further ensure the long-term reliable operation of the equipment. The modular slot design facilitates installation, maintenance and system expansion. Parameter setting, GSD file import and fault diagnosis can be quickly completed through special configuration software, with ladder logic sample files attached, reducing programming and operation and maintenance costs, supporting automatic bus parameter calculation and online slave diagnosis, and providing stable and efficient communication support for the efficient coordination of Rockwell ControlLogix PLC and PROFIBUS network.
