Pacific Scientific SCE905AN-002-01 Single axis digital servo drive

Pacific Scientific SCE905AN-002-01 Single axis digital servo drive

Specific Parameters​

Electrical Parameters​

Input Voltage 90-264VAC, 47-63Hz, single-phase AC input​

Continuous Output Current 5.3A at 25℃ with convection cooling, 5.3A at 50℃ with forced air cooling​

Peak Output Current 10.6A, meeting the motor’s instantaneous overload requirements​

Control Mode Supports position, speed, torque three closed-loop control, based on vector control algorithm​

Command Interface No external option card, supports analog or incremental digital command signal input​

Firmware Configuration Equipped with standard basic servo control software​

Protection Functions Integrates overload, short circuit, undervoltage protection, automatically cuts off output and alarms​

Feedback Interface Adapts to incremental photoelectric encoder, supports real-time detection of motor rotor speed​

Power Consumption Typical operating power consumption ≤500W, standby power consumption ≤10W​

Mechanical Parameters​

Overall Dimensions Compact design, compatible with standard servo drive installation dimensions (based on series general specifications when no specific data is available)​

Weight Approximately 1.2kg, lightweight structure facilitating integrated installation​

Mounting Method 19-inch standard cabinet rack-mounted installation or panel-mounted installation​

Housing Material Industrial-grade high-strength aluminum alloy housing with good heat dissipation performance​

Cooling Method Fanless convection cooling, optional forced air cooling upgrade​

Connection Method Back plug-in terminal block connection with screw-fastened wiring​

Status Indication Equipped with Power (green), Run (yellow), Fault (red) LED indicators​

Environmental Parameters​

Operating Temperature -40℃ to 85℃, no performance derating over the entire temperature range​

Storage Temperature -40℃ to 85℃, meeting extreme storage and transportation requirements​

Relative Humidity 5% to 95% (non-condensing), adapting to high-humidity industrial scenarios​

Vibration Resistance Complies with industrial vibration standards, tolerating regular workshop vibration environments​

EMC Compliance Meets industrial equipment EMC specifications, avoiding interference with surrounding equipment​

Product Performance​

High precision of three closed-loop control, realizing accurate regulation of motor position, speed and torque based on vector control technology and PID adjustment​

Strong load adaptability, 5.3A continuous current and 10.6A peak current output covering medium-power motor drive needs​

Excellent cooling efficiency, fanless convection design reduces operating noise while ensuring heat dissipation stability​

Comprehensive protection mechanism, multiple electrical fault protection functions respond quickly to avoid damage to motors and drives​

High integration, operable without external option cards, simplifying system architecture and installation process​

Strong environmental adaptability, wide voltage input and wide temperature operating range adapting to complex industrial power supply and environmental conditions​

Fast response speed, real-time feedback to external command signals ensuring smooth movement of automation equipment​

High operational reliability, high-quality components and compact structure design reducing failure rate​
