MTL 8507-BI-DP Bus interface module

MTL 8507-BI-DP Bus interface module

Specific Parameters​

Core and Function Parameters​

Product Type PROFIBUS-DP Bus Interface Module​

Manufacturer Eaton MTL (formerly MTL Instruments)​

Model MTL 8507-BI-DP​

Series MTL 8000 Series​

Communication Protocols DeviceNet, PROFIBUS-DP​

Interface Type 2 Discrete Inputs, 2 Transistor Outputs​

Installation Method DIN Rail Mounting​

Compatible Carrier 8701-CA-BI Redundant Interface Module Carrier​

Operation Mode Redundant Operation Supported​

Storage Type Non-volatile Configuration Memory​

Protection Rating IP67​

Housing Material 316 Stainless Steel​

Diagnostic Function PROFIBUS Extended Diagnostics Supported​

Compatible Devices PAC 8000 Series I/O Modules, PROFIBUS-DP Hosts​

Electrical Parameters​

Supply Voltage 16-35V DC (standard 24V DC)​

Input Voltage Range 10V DC​

Maximum Load Current per Channel 1A​

Isolation Voltage 1000V DC​

LAN Speed Up to 12 Mbaud​

Signal Range 0-20mA, 4-20mA​

Accuracy ±0.1% of Span​

Physical and Environmental Parameters​

Overall Dimensions 140mm×100mm×50mm (L×W×H)​

Weight Approximately 0.5kg​

Operating Temperature Range -40°C to +85°C​

Product Performance​

Supports PROFIBUS network speed up to 12 Mbaud, enabling high-speed data transmission with fast host response​

Equipped with non-volatile memory for persistent configuration data storage, which is automatically loaded after system restart for convenient deployment​

Supports redundant operation mode, with dual modules working in parallel and real-time status monitoring, enabling seamless switching in case of failure with high reliability​

Integrates galvanic isolation technology with isolation voltage up to 1000V DC, resisting electrical noise and transient overvoltages with strong anti-interference capability​

316 stainless steel housing with IP67 protection rating, dustproof, waterproof and corrosion-resistant, adapting to harsh industrial environments​

Supports HART pass-through function for monitoring and configuring HART devices with strong functional expandability​

Accuracy up to ±0.1% of span, ensuring high signal transmission accuracy to meet high-precision industrial control requirements​

Adapts to 24 I/O modules and supports extended diagnostics, providing real-time feedback on module and channel status for high operation efficiency​
