MOTOROLA MVME6100 Bus based single board computer

MOTOROLA MVME6100 Bus based single board computer

SPECIFIC PARAMETERS​

Brand MOTOROLA​

Product Series MVME Series Industrial VME Bus Single-board Computers​

Product Type Industrial-grade Embedded VME Bus Single-board Computer​

Model MVME6100​

Processor PowerPC MPC7457 1GHz Clock Speed​

Memory Capacity Standard 512MB DDR SDRAM Maximum Support 1GB​

Storage Capacity 16MB Flash ROM Optional 8GB CompactFlash Card​

Bus Type VME64x 32/64-bit Maximum 400MB/s Transfer Rate​

Communication Interfaces 2 10/100/1000Mbps Ethernet Ports 2 RS232/422/485 Serial Ports 1 USB 2.0 Port 1 VME64x System Management Interface​

Display Interface 1 VGA Port Supports 1280×1024 Resolution​

I/O Interfaces 32-channel Configurable Digital Input/Output 2 CAN Bus Interfaces 1 PCI Mezzanine Card Interface​

Working Voltage 5V DC ±5% 12V DC ±10% -12V DC ±10%​

Working Temperature -40℃ to 70℃​

Storage Temperature -55℃ to 85℃​

Relative Humidity 5% to 95% Non-condensing (No Dew Formation)​

Protection Level IP20 (Board-mounted Installation)​

Installation Method VME Bus Rack Installation Standard 3U VME Board Size​

Size 160mm×100mm×233mm (Length×Width×Height, 3U VME Standard Size)​

Weight 0.9kg​

Power Consumption Typical 25W Maximum 35W​

Certification Qualification CE FCC UL IEC 61010-1 VME64x Certification​

Compatible System VxWorks QNX Linux Industrial DCS/SCADA Systems VME Bus Control Systems​

Diagnostic Functions Memory Self-test Processor Self-diagnosis Bus Communication Fault Detection Power Supply Abnormality Monitoring Temperature Monitoring and Alarm​

Anti-interference Level Complies with EN 55032/EN 61000-6-2 Industrial EMC Standards​

Vibration and Shock Resistance Complies with MIL-STD-810G Standard​

MTBF (Mean Time Between Failures) ≥800,000 Hours​

Heat Dissipation Method Conductive Heat Dissipation + Natural Heat Dissipation Fanless Design​

PCB Process Multi-layer Ruggedized PCB Anti-interference Wiring Design​

Clock Accuracy Built-in Real-time Clock Supports NTP Time Synchronization​

PRODUCT PERFORMANCE​

Equipped with PowerPC MPC7457 1GHz processor, combined with 512MB-1GB DDR SDRAM, it has strong real-time computing capability, enabling efficient processing of complex industrial control algorithms and massive real-time data​

Supports VME64x 32/64-bit bus with maximum 400MB/s transfer rate, ensuring high speed and stability of data interaction between multiple modules​

Fanless ruggedized design and conductive heat dissipation scheme, avoiding mechanical failures and dust accumulation, adapting to embedded installation environments without forced ventilation​

Industrial-grade wide-temperature adaptability, can work stably in the temperature range of -40℃ to 70℃ and 5%-95% non-condensing humidity environment, withstanding extreme industrial working conditions​

Comprehensive coverage of multi-protocol communication interfaces, supporting Ethernet, CAN, RS232/422/485, etc., enabling seamless interconnection with industrial sensors, actuators and upper computers​

32-channel configurable digital I/O and 2 CAN bus interfaces, flexibly adapting to the connection needs of various industrial on-site equipment, improving system integration flexibility​

Compatible with mainstream embedded real-time operating systems such as VxWorks and QNX, with fast real-time response speed, meeting the millisecond-level command execution requirements of industrial control​

Built-in comprehensive self-test and diagnostic mechanisms, which can real-time monitor hardware status and communication links, with timely fault early warning, facilitating rapid location and troubleshooting​

3U VME standard size design, fully compatible with existing VME bus racks, can directly replace old modules, simplifying system upgrade and transformation processes​

Vibration and shock resistance performance complies with MIL-STD-810G standard, maintaining stable operation in high-vibration environments such as rail transit and marine equipment​
