Specific Parameters​

Core and Function Parameters​

Product Type Industrial-grade Single-channel Signal Conditioning Module​

Manufacturer Microset​

Model 104988-E03​

Series Microset 104988 Series​

Input Signal Types Thermocouple (J/K/T/E/R/S/B types), RTD (Pt100/Pt1000), Strain Signal (±5mV/V)​

Output Signal Types Standard Industrial Signals (4-20mA DC, 0-10V DC, optional)​

Signal Processing Functions Signal Amplification (gain 1-1000x adjustable), Low-pass Filter (cutoff frequency 0.1-100Hz adjustable), Linearization Compensation​

Isolation Level 3-way electrical isolation (input-output-power), isolation voltage 2500V AC (1 minute)​

Installation Method DIN Rail Mounting (35mm standard rail)​

Power Supply 24V DC (18-30V DC wide-range compatible)​

Compatible Systems PLC, DCS, Data Acquisition Card (DAQ)​

Protection Functions Input Over-voltage Protection (±30V DC), Output Over-current Protection (max 30mA)​

Status Indication Power (PWR), Signal Normal (SIG) LED Indicators​

Certification Standards CE, UL, RoHS, ATEX (explosion-proof certification for hazardous areas)​

Electrical and Performance Parameters​

Input Impedance ≥10MΩ (voltage signal), ≤0.1Ω (current signal)​

Output Accuracy ±0.1% full scale (at 25°C ambient temperature)​

Temperature Drift ≤0.005% full scale/°C (within -20°C to 60°C)​

Response Time ≤10ms (from signal change to output stability)​

Power Consumption ≤1.5W (when powered by 24V DC)​

Common Mode Rejection Ratio (CMRR) ≥100dB (50/60Hz)​

Differential Mode Rejection Ratio (DMRR) ≥80dB​

Output Load Capacity Current Output: max 500Ω; Voltage Output: min 10kΩ​

Physical and Environmental Parameters​

Overall Dimensions 12.5mm×100mm×65mm (W×D×H)​

Weight Approximately 80g​

Operating Temperature Range -20°C to 60°C​

Storage Temperature Range -40°C to 85°C​

Relative Humidity 5%-95% (non-condensing, no dew)​

Protection Rating IP20 (front panel)​

Housing Material Flame-retardant ABS Plastic (UL94 V-0 grade)​

Product Performance​

Output accuracy up to ±0.1% full scale and temperature drift as low as 0.005% full scale/°C, ensuring accurate signal acquisition in wide-temperature environments​

3-way isolation (input-output-power) with 2500V AC and CMRR ≥100dB, effectively suppressing electromagnetic interference in industrial fields with strong signal stability​

Supports multiple sensor inputs and standard signal outputs, with adjustable gain and filter parameters, adapting to diverse signal processing needs with high flexibility​

Integrates over-voltage and over-current protection to prevent module damage caused by sensor or backend equipment failures with high safety​

12.5mm ultra-thin width design with DIN rail mounting saves cabinet space, suitable for high-density deployment scenarios​

Wide operating temperature range of -20°C to 60°C, compatible with harsh industrial environments with excellent environmental adaptability​

Real-time feedback via power and signal status LEDs enables quick fault location with high operation and maintenance efficiency​

Low-power design (≤1.5W) ensures low energy consumption during long-term operation, reducing overall energy consumption of industrial systems​
