Metso D200137 Integrated module for servo drive and network communication

Metso D200137 Integrated module for servo drive and network communication

Specific Parameters​

Electrical Parameters​

Input Voltage 24V DC, compatible with industrial standard DC power supply systems​

Output Current 10A, meeting the power demand of servo motor drive​

Bus Speed 66MHz, achieving high-speed data transmission relying on Unity ASIC chip​

Communication Speed Up to 921kbps for 4-wire/8-wire products, up to 460kbps for interface products​

Memory Capacity On-board DDR memory 128-256MB, supporting 2-256MB E-disk storage​

Communication Interfaces Standard 2 serial ports, 2 USB ports, 1 standard parallel port​

Expansion Interfaces Supporting on-board IDE hard disk drive interface, adapting to PCI/PCI-X expansion slots​

Communication Protocols Supporting RS-232/422/485 (software switchable), compatible with standard industrial communication protocols​

Operating Systems Adapting to Windows XP, XPE, WinCE 6.0 and Linux systems​

Mechanical Parameters​

Overall Dimensions 100mm×75mm×45mm, compact design saves installation space​

Weight 0.5kg, lightweight structure facilitates integrated installation​

Mounting Method Adapting to standard servers and 2U rack-mounted servers, supporting PCI/PCI-X slot installation​

Port Configuration 4-32 ports optional, supporting models with cables or independent interfaces​

Housing Characteristics Adopting robust structural design, with impact resistance and vibration resistance​

Adaptation Standards Compatible with 3.3V/5V voltage specifications, supporting 32-bit and 64-bit system architectures​

Environmental Parameters​

Operating Temperature -20℃ to 60℃, no performance derating over the entire temperature range​

Storage Temperature -40℃ to 85℃, meeting extreme storage and transportation requirements​

Environmental Adaptability Withstanding harsh industrial environments, with dustproof and moisture-proof capabilities​

Anti-interference Performance Complying with industrial EMC standards, tolerating workshop electromagnetic interference​

Operational Stability Supporting long-term continuous operation, adapting to 24-hour industrial production needs​

Product Performance​

High control precision, realizing accurate position and speed control of servo motors to ensure motion control accuracy​

Fast communication speed, 66MHz bus with 921kbps transmission rate, no delay in data transmission​

Strong expansion capability, 4-32 ports optional, supporting simultaneous connection and data processing of multiple devices​

Excellent compatibility, adapting to multiple operating systems and PCI/PCI-X slots, seamlessly connecting to existing systems​

Good installation convenience, designed for quick integration, can be put into use without complex debugging​

High operational reliability, industrial-grade structural design and component selection, reducing downtime​

Wide adaptability, software-switchable communication modes, meeting different device connection needs​

Strong storage capability, large-capacity memory and E-disk configuration, ensuring data storage security​
