KONGSBERG RSER200-4 Safety relay output module

KONGSBERG RSER200-4 Safety relay output module

Specific Parameters

BrandKONGSBERG (Kongsberg, Norwegian original factory, safety business integrated with Triconex), Product Series Kongsberg RSER200 Series

Product Type Industrial-Grade Triple Modular Redundancy (TMR) Safety Relay Output Module, Safety Instrumented System (SIS) Executive Component, Original Authentic Spare Part

Model KONGSBERG RSER200-4 (Part Number 603444, Redundancy Type TMR Triple Modular Redundancy)

Country of Origin Norway (Produced by KONGSBERG original factory, safety business derived from Triconex integration)

Compatible Devices KONGSBERG (Triconex) Tricon Safety Instrumented System, Trident TMR Safety Instrumented System, Tricon 3503E Dedicated Rack, Emergency Shutdown Valves, Solenoid Valves, Fire System Release Valves, Industrial Safety Controllers

Core Functions Receive TMR Controller Safety Instructions, Drive Final Actuators, Triple Modular Redundancy Output, Fail-Safe Action, Relay Status Self-Diagnosis, Contact Abnormality Detection, System Status Feedback, Backplane Bus Communication

Module Type Safety Relay Output Module, Triple Modular Redundancy (TMR) Architecture, Built-in Three Independent Channels A, B, C

Output Type Relay Contact Output, Form C Changeover Contacts, Supporting NO/NC Selection

Output Channels and Architecture Triple Modular Redundancy (TMR) Output, Supporting 2oo3 (Two-out-of-Three) Voting Logic

Contact Capacity 5A @ 30VDC, 2A @ 250VAC, Can Directly Drive Solenoid Valves, Indicator Lights and Other Actuators

Fail-Safe Mode De-energize to Trip, Contacts Guide to Safe State When Power is Lost

Interface with Controller Communicate with TMR Controller via Triconex System Backplane Bus (TriBus)

Power Supply Voltage 24VDC±20% (Backplane Powered), Low to Moderate Power Consumption, Suitable for Industrial Continuous Operation

Operating Temperature Range 0℃ to 60℃ (Standard Working Condition), -40℃ to 70℃ (Harsh Working Condition)

Storage Temperature Range -55℃ to 85℃

Relative Humidity 5% to 95%, Non-Condensing

Protection Class IP20 (Rack Mount Version), Adaptable to Higher Protection Class Variants

Vibration and Shock Complies with IEC 60068-2-6 (10-500Hz, 5g), IEC 60068-2-27 (30g, 11ms) Standards

Physical Dimensions Width 22.5mm, Height 99mm, Depth 114.5mm (Rack Mount Version, Adaptable to 35mm DIN Rail)

Physical Weight Approximately 0.33kg (Rack Mount Version)

Mounting Method Plug-in Installation, Adaptable to Tricon System Dedicated Rack (3503E Rack) I/O Slots, Supporting 35mm DIN Rail Mounting

Connector Type Removable Screw Terminal Blocks, Wiring Capacity 0.2-2.5mm²

Diagnostic Function Built-in Self-Diagnostic Module, Can Detect Relay Coil Faults, Contact Welding/Action Abnormalities, Report Fault Status to Controller via Backplane Bus, Equipped with Power, Run, Fault Indicator Lights

Product Material Industrial-Grade High-Strength Flame-Retardant Enclosure, Conformal Coated PCB, High-Temperature Resistant Insulation Material, Built-in Anti-Corrosion and Anti-Electromagnetic Interference Protection Components

Special Functions Triple Modular Redundancy Design, Single Point Fault Does Not Affect System Safety Action; Fail-Safe Design, Contacts Automatically Guide to Safe State When Power is Lost; Supports Online Replacement, Module Can Be Plugged and Unplugged When Backplane is Powered; Excellent Anti-Electromagnetic Interference Performance, Adaptable to High-Risk Industrial Scenarios

Product Performance

KONGSBERG RSER200-4 is an original Kongsberg device with extremely strong adaptability, which can be perfectly matched with KONGSBERG (Triconex) Tricon and Trident series safety instrumented systems, seamlessly integrated into various high-risk industrial safety control scenarios, no additional adaptation components required, greatly reducing system integration complexity and commissioning costs. The product has outstanding safety and reliability, adopts a Triple Modular Redundancy (TMR) architecture, built-in three independently isolated relay channels, supports 2oo3 voting logic, even if a single channel fails, the other two healthy channels can still ensure the normal execution of safety actions, minimizing the probability of system failure caused by single point faults. The product strictly follows the fail-safe principle, and the contacts automatically guide to a safe state when power is lost, which can effectively avoid safety accidents caused by equipment faults in the process, and support the system to reach SIL 3 safety integrity level. The product adopts industrial-grade high-quality components and conformal coated PCB design, has excellent anti-electromagnetic interference and anti-vibration impact capabilities, can operate continuously and stably in standard working conditions of 0℃ to 60℃ and harsh working conditions of -40℃ to 70℃, has a long mean time between failures, and is adaptable to harsh environments such as dust, temperature and humidity fluctuations, and high salt spray at sea. Built-in complete self-diagnostic mechanism, can real-time detect relay status and report faults, facilitating maintenance personnel to early warn and handle, plug-in installation design facilitates online replacement and system expansion, can be put into use without complex commissioning, greatly improving operation and maintenance efficiency, and providing stable, reliable and accurate safety execution support for high-risk industrial scenarios.
