KOLLMORGEN SERVOSTAR TM620 S62000 High performance servo drive
The KOLLMORGEN SERVOSTAR TM620 S62000 is a high - performance servo drive belonging to the KOLLMORGEN SERVOSTAR series. This drive achieves high - precision positioning and dynamic response of the mechanical system by precisely controlling the rotation angle and speed of the motor. It mainly receives instructions from the controller and then drives the motor to operate, enabling the motor to run along the desired motion trajectory to meet the requirements of high - precision and high - response speed in various automation applications.
wechatPhone 15359273787
Phone: 15359273787
Email: sales@zzhuie.com
connect：Mya
KOLLMORGEN SERVOSTAR TM620 S62000 High performance servo drive
Specific Parameters
- Input Voltage: Three – phase 200 – 230VAC, ±10%
- Continuous Output Current: 30A
- Peak Output Current: 60A (for 1 second)
- Control Modes: Supports speed control, torque control, and position control modes
- Feedback Interface: Can be connected to resolvers, incremental encoders, absolute encoders, and supports various feedback protocols such as Hiperface and EnDat
- Communication Interface: Standard Ethernet interface, supports EtherNet/IP and Modbus TCP communication protocols; CANopen, DeviceNet and other communication interfaces can be expanded
- Overload Capacity: 150% of rated current for 60 seconds; 200% of rated current for 3 seconds
- Operating Temperature Range: -10°C to +50°C
- Storage Temperature Range: -25°C to +70°C
- Relative Humidity: 5% to 95%, non – condensing
- Protection Level: IP20
- Dimensions (Width × Height × Depth): 150mm×300mm×200mm
- Weight: Approximately 3kg
Product Performance
- High – Precision Control: It can accurately control the rotation angle and speed of the motor, achieving positioning accuracy at the micron – or even nanometer – level, ensuring the precise operation of the mechanical system, and is suitable for automated equipment with extremely high requirements for positioning accuracy.
- Powerful Driving Ability: It can drive large – load and high – torque motors, with a continuous output current of 30A and a peak output current of 60A, which can meet the power requirements in various complex application scenarios.
- Multi – mode Control: It has three control modes: speed, torque, and position. Users can flexibly switch according to different application requirements, enhancing the versatility and applicability of the drive.
- Rich Communication Interfaces: It supports a variety of communication protocols and interfaces, facilitating data exchange and integration with other devices and systems. It can easily build complex automated control systems to achieve various complex motion controls and collaborative work.
- Good Stability and Reliability: It adopts advanced circuit design and high – quality components, and has complete over – current, over – voltage, and over – temperature protection functions. It can operate stably in harsh industrial environments, reducing equipment failure and downtime.
- Convenient Debugging and Maintenance: It provides an intuitive debugging software. Users can easily perform parameter setting, status monitoring, and fault diagnosis through the software, reducing debugging and maintenance difficulties and improving work efficiency.
