KOLLMORGEN E33NCHA-LNN-NS-00 hybrid stepping motor

Specific Parameters

Rated Torque: Ranging from 1.7 Nm to 3.3 Nm, it can provide stable and sufficient torque output to meet the operating requirements of equipment under different load conditions.
Rated Voltage: 230V, which is compatible with common industrial power standards and is convenient to connect to various industrial power supply systems.
Rated Current: 6.3A, ensuring the stable operation of the motor under rated conditions and providing the necessary current support for the efficient operation of the motor.
Rated Speed: 3000 revolutions per minute, it can operate continuously and stably at this speed, meeting the operating speed requirements of general industrial equipment.
Maximum Speed: 5000 revolutions per minute, it can reach this speed within a short time, suitable for application scenarios with an instant speed – up requirement.
Step Angle: 1.8°, the small step angle ensures that the motor has high positioning accuracy and can meet the requirements of most precision motion control.
Number of Phases: 2 – phase, the two – phase design helps the motor start and operate smoothly, improving operation stability.
Insulation Class: Class B, with good insulation performance, it can effectively prevent electrical failures and ensure the safe operation of the motor under normal working voltage.
Protection Class: IP54, it has the ability to prevent dust and water splashing, and can operate reliably in industrial environments with certain dust and a small amount of water splashing.
Cooling Method: Self – cooling, no additional cooling equipment is required, reducing system complexity and maintenance costs. It dissipates heat relying on its own structure to ensure the normal operating temperature of the motor.
Shaft Diameter: 14mm, the shaft diameter is reasonably sized and can be adapted to a variety of transmission equipment to ensure effective power transmission.
Shaft Length: 68mm, it meets the installation space requirements of common equipment and is convenient for connection and assembly with other mechanical components.
Weight: 2.7kg, the overall weight is moderate, which not only ensures the stability of the motor structure but also does not bring excessive burden to the installation and movement of the equipment.
Overall Dimensions: 105mm x 105mm x 80mm, the compact design allows the motor to be easily installed and laid out in a limited space, suitable for equipment with strict space requirements.

Product Performance

High – Precision Control: The 1.8° step angle, combined with advanced drive control technology, can achieve precise position control with high repeat positioning accuracy. It is suitable for applications with strict requirements for position accuracy, such as tool positioning in CNC machine tools and material sorting and positioning in automated production lines, ensuring the accuracy and consistency of equipment operation and effectively improving product processing and production quality.
High – Torque Output: Within the rated torque range of 1.7 Nm to 3.3 Nm, the motor can maintain a stable torque output at different speeds. Even when the load changes, it can quickly adjust the output torque to ensure the smooth operation of the equipment. It is suitable for industrial equipment that needs to overcome large resistance, such as material conveying and handling equipment in packaging machinery.
Low – Noise Operation: The hybrid structure design and optimized motor manufacturing process effectively reduce the vibration and noise during the motor’s operation, providing a quiet operating condition for workplaces with requirements for noise environment, such as medical equipment and electronic manufacturing workshops, avoiding noise interference with operators and equipment operation.
Fast Response Characteristics: The motor can quickly respond to control signals. When starting, stopping, and switching speeds, the response time is short, and the dynamic performance is good. It can meet the requirements of frequent start – stop and rapid adjustment of the operating state of the equipment, improving the operating efficiency and production rhythm of the equipment, and is suitable for the links in the automated production line that require rapid action.
High Reliability: By using high – quality materials and undergoing strict quality inspection processes, the motor has good anti – interference ability and the ability to adapt to harsh environments. It can operate stably for a long time in industrial environments such as high temperature, high humidity, and high dust, reducing equipment failure downtime, lowering enterprise maintenance costs, and improving production continuity and reliability.
