Ics Triplex T9100 Safety controller module

Ics Triplex T9100 Safety controller module

Specific Parameters​

Electrical Parameters​

Operating Voltage Dual 24VDC redundant power supply, input range 18-32VDC​

Processor Configuration 3 independent industrial-grade multi-core processors, implementing TMR voting logic​

Memory Capacity 1GB DDR4 RAM, 8GB Flash storage, meeting program and data storage requirements​

Communication Protocols Compatible with Tricon Bus, Modbus TCP/IP, IEC 61850, OPC UA​

Communication Interfaces 4 Gigabit Ethernet ports, 2 RS485 interfaces, supporting redundant communication​

I/O Expansion Capacity Up to 32 I/O modules expandable, supporting digital, analog, and special function modules​

Safety Level Complies with IEC 61508 standard, achieving SIL 3 Safety Integrity Level​

Protection Features Built-in reverse power protection, overvoltage protection, overcurrent protection, electromagnetic shielding protection​

Certification Standards Compliant with IEC 61508, IEC 61511, UL 1998, ATEX certification standards​

Mechanical Parameters​

Overall Dimensions 210mm×175mm×85mm, compact structure suitable for standard industrial cabinets​

Weight Approximately 1.8kg, lightweight design facilitating deployment and maintenance​

Mounting Method 35mm DIN rail mounting or rack mounting, compatible with Trusted series standard cabinets​

Housing Material Industrial-grade high-strength metal shell with electromagnetic shielding and mechanical protection performance​

Connection Method Plug-in backplane connector + screw-fastened terminals, compatible with shielded control cables​

Protection Rating IP20, suitable for indoor industrial control cabinet environments​

Status Indication Equipped with 3 independent channel operation LED lights, system power light, fault alarm light, and LCD status display​

Environmental Parameters​

Operating Temperature -20℃ to 60℃, no performance derating over the entire temperature range​

Storage Temperature -40℃ to 85℃, meeting extreme storage and transportation requirements​

Relative Humidity 5% to 95% (non-condensing), suitable for high-humidity industrial scenarios​

Vibration Resistance Complies with IEC 60068-2-6 standard, 2g acceleration at 5Hz-500Hz frequency range​

Shock Resistance Complies with IEC 60068-2-27 standard, 15g acceleration (11ms duration)​

EMC Compliance Complies with EN 55014-1, EN 55014-2 standards, meeting anti-external electromagnetic interference requirements​

Product Performance​

Reliable redundant design: TMR triple modular hardware architecture + independent voting logic, avoiding system failure caused by single-point failure​

Excellent safety level: SIL 3 certification meets safety requirements of high-risk scenarios, with short mean time to repair​

Strong processing capability: Multi-core processor parallel computing, control cycle as low as 1ms, ensuring real-time response​

Wide expansion compatibility: Supports 32 I/O module expansion and multi-protocol communication, adapting to complex control systems​

Comprehensive diagnostic functions: Real-time monitoring of channel status, module faults, and communication abnormalities, diagnostic coverage ≥99%​

Strong environmental adaptability: Wide temperature operation and high humidity tolerance, withstanding harsh industrial working conditions such as dust and electromagnetic interference​

Convenient installation and maintenance: Modular design + hot-swap function, supporting online module replacement without shutdown​

High operational stability: Industrial-grade metal shell and multiple electrical protections, Mean Time Between Failures (MTBF) ≥1,000,000 hours​
