HIMA X-DI1601 985210222 Secure digital input module

HIMA X-DI1601 985210222 Secure digital input module

SPECIFIC PARAMETERS​

Brand HIMA​

Product Series X-Series Safety Control Module​

Product Type 16-channel Safety-related Digital Input Module​

Order Number 985210222​

Number of Input Channels 16​

Input Voltage 24VDC 19-30VDC Wide Range Adaptation​

Input Current Maximum 4mA per Channel​

Input Type Dry Contact Wet Contact​

Response Time ≤1ms​

Working Temperature -25℃ to +70℃​

Storage Temperature -40℃ to +85℃​

Relative Humidity 5% to 95% Non-condensing​

Protection Level IP20 (In Cabinet) IP67 (Specific Protection Version)​

Safety Level SIL3 (SIL4 Supported in Some Configurations)​

Communication Interface PROFIBUS DP PROFINET Ethernet/IP Modbus TCP​

Size 115mm×45mm×23mm (150mm×100mm×60mm for Some Versions)​

Weight 0.2kg (0.5kg for Some Versions)​

Installation Method Cabinet Rail Snap-in​

Certification Qualification TÜV SÜD Certification IEC 61508 IEC 61511 IEC 62601​

Isolation Feature Electrical Isolation Between Channels and Backplane​

Power Consumption Low Power Consumption Design​

PRODUCT PERFORMANCE​

Adopt 16-channel integrated design, which can realize synchronous acquisition of multi-region discrete safety signals and improve the access density and management efficiency of system signals​

Has a signal response time of ≤1ms, which can quickly capture abnormal states of on-site equipment and ensure the timely triggering of safety interlock commands​

Built-in channel-level electrical isolation circuit, which can effectively block electromagnetic interference in industrial sites and ensure the accuracy and stability of safety signal acquisition​

Supports open-circuit and short-circuit fault diagnosis, can real-time feedback channel operation status, achieve accurate fault location and alarm, and reduce the risk of hidden faults​

Complies with the highest safety level standard of SIL3, and can support SIL4 in some configurations, and can be directly applied to high-risk control scenarios such as emergency shutdown and fire and gas monitoring​

Adopts redundant circuit design, single-point faults do not affect the overall function of the system, ensuring the continuous stability of the safety control link​

Adapt to multi-protocol industrial buses, and can realize seamless data interaction with third-party control systems and HIMA safety main control units, improving system integration flexibility​

Industrial-grade wide-temperature components can adapt to extreme temperature environments of -25℃ to +70℃, meeting the deployment needs of industrial sites in multi-climate regions​

Compact modular structure, which can realize high-density deployment in narrow control cabinets, and supports hot-swappable maintenance to reduce equipment downtime​

Low-power design can reduce the overall energy consumption and heat dissipation pressure of the system, improving the economy of long-term system operation​
