HIMA F6217 984621702 Analog input module
Specific Parameters
Electrical Parameters
Power Supply Voltage: 24V DC, supporting ±10% voltage fluctuation, independent module power inputInput Channels: 4 differential analog input channels, supporting parallel acquisition between channelsInput Signal Types: Compatible with 4-20mA DC current signals, 0-10V DC voltage signals, supporting NAMUR NE 43 standard sensorsResolution: 16-bit AD conversion resolution, total measurement error ±0.1% Full Scale (FS)Isolation Characteristic: 2kV RMS electrical isolation between channels and between channels and ground, independent isolation between power supply and signal circuitsResponse Time: ≤200ms (from signal input to data upload to controller)Diagnostic Functions: Built-in detection for channel faults (open circuit, short circuit), overvoltage, and AD conversion abnormalities; fault information uploaded in real time via busSafety Certifications: SIL 2 (IEC 61508), PL d (EN ISO 13849-1), CE, UL 508 certificationCommunication Protocol: Supports HIMA SafeBus safety bus, compatible with Profibus DP (requires matching communication expansion module)
Environmental Parameters
Operating Temperature: -40℃ to +70℃ (non-condensing environment, compliant with IEC 60068-2-1/2 standard)Storage Temperature: -40℃ to +85℃Relative Humidity: 5% to 95% (non-condensing, compliant with IEC 60068-2-3 standard)Protection Rating: IP20 (module itself, must be installed in a closed control cabinet)Vibration Resistance: 10-55Hz frequency range, 0.75mm amplitude (sine wave), compliant with IEC 60068-2-6 standardEMC Compliance: Meets EN 61000-6-2 (industrial environment immunity) and EN 61000-6-4 (industrial environment emission limits) standards
Mechanical Parameters
Overall Dimensions: 140mm (L) × 100mm (W) × 32mm (H)Housing Material: Die-cast aluminum alloy housing, anti-static powder coating on surface, with RFI shielding functionWeight: Approximately 0.4kgMounting Method: 35mm standard DIN rail mounting, supporting hot swapping with power onWiring Method: Plug-in spring terminals, adapting to 0.5-2.5mm² single/multi-strand copper wires, terminals with anti-misplug designStatus Indication: 1 LED indicator per channel (green: normal acquisition; red: channel fault), 1 system operation LED (yellow)
Product Performance
High safety and reliability: Certified with SIL 2/PL d safety standards, channel-level electrical isolation and comprehensive fault diagnosis design achieve a fault diagnosis coverage rate of ≥95%, enabling quick location of abnormalities such as open circuits and short circuits, and avoiding safety risks caused by signal distortion.
Accurate signal acquisition: 16-bit resolution and ±0.1% FS measurement error ensure the acquisition accuracy of key analog signals such as pressure and temperature, adapting to high-precision sensors and meeting the strict requirements of safety control for data accuracy.
Strong anti-interference capability: 2kV RMS electrical isolation and EMC compliance design can effectively suppress electromagnetic interference in industrial fields (e.g., interference from inverters and high-power motors), ensuring no signal drift or distortion during acquisition.
Excellent maintenance convenience: Supports hot swapping, allowing module replacement without shutting down the system; LED indicators intuitively feed back channel status, and fault information is uploaded to the controller via the bus, reducing fault troubleshooting time to within 5 minutes.
Wide environmental adaptability: The wide temperature design of -40℃ to +70℃ covers extremely cold and high-temperature industrial scenarios (e.g., outdoor cabinets in northern winter, high-temperature chemical plant areas); IP20 protection and vibration resistance adapt to complex installation environments.
