General Electric T60-E00-HCH-F8F-H6T-M8F-P6T-UXX-W6T Transformer Protection Relay

General Electric T60-E00-HCH-F8F-H6T-M8F-P6T-UXX-W6T Transformer Protection Relay

    The GE T60-E00-HCH-F8F-H6T-M8F-P6T-UXX-W6T is a highly sophisticated Transformer Protection Relay designed for comprehensive safeguarding, control, and monitoring of transformer systems. It features advanced asset monitoring capabilities, making it an essential component in power systems.

Number of Data Logging Channels:1 to 16

User Programmable LEDs:48 plus trip and alarm

Breaker Flashover Operating Quantity:phase current, voltage, and voltage difference

Noise:0 dB

Phase Directional Overcurrent Sensitivity Threshold:0.05 pu

Power Consumption:Typical = 15 to 20 W/VA, Maximum = 45 W/VA

RTD Input Accuracy:±2°C

Teleprotection Input Points:16

DCMA Output Driving Signal:any FlexAnalog quantity

Humidity Operating Up To:95%

Load Encroachment Angle Accuracy:±2°

Operating Temperature:–40 to 60°C

RTD Input Types:3-wire: 100 Ω Platinum, 100 and 120 Ω Nickel, 10 Ω Copper

AC Current Withstand:20 ms at 250 times rated, 1 sec at 100 times rated

Ambient Storage Temperature:–40 to 85°C

Ingress Protection:IP20 front, IP10 back

Maximum Altitude:2000 m

RMS Voltage Accuracy:±0.5% of reading from 10 to 208 V

RTD Input Isolation:36 Vpk

    The General Electric T60-E00-HCH-F8F-H6T-M8F-P6T-UXX-W6T is designed for the highest standards of transformer protection and management.

     With its sophisticated data logging channels and user-programmable LEDs, it ensures efficient and reliable operation across various industrial settings.

     Its noise immunity and phase directional overcurrent sensitivity threshold guarantee precise measurements even under harsh conditions.

     Furthermore, the high accuracy of RTD inputs makes it perfect for applications requiring accurate temperature sensing.

     This unit’s broad compatibility with different types of RTDs (Resistance Temperature Detectors) and its ability to withstand high currents make it a versatile addition to any industrial control setup.

     The T60-E00-HCH-F8F-H6T-M8F-P6T-UXX-W6T is engineered to withstand extreme temperatures and humidity levels, ensuring optimal performance in diverse environments.
