GE WES5302-111 Industrial Ethernet Switches

GE WES5302-111 Industrial Ethernet Switches

SPECIFIC PARAMETERS​

Brand GE​

Product Series Industrial Network WES Series High-end Full Gigabit Managed Switch​

Product Type Industrial-grade Full Gigabit Enhanced Managed Ethernet Switch​

Model WES5302-111​

Working Voltage 24VDC Wide Range Adaptation 18-36VDC​

Working Temperature -40℃ to 75℃​

Storage Temperature -55℃ to 85℃​

Relative Humidity 5% to 95% Non-condensing (No Dew Formation)​

Protection Level IP40 (Rail-mounted Installation)​

Installation Method 35mm DIN Rail Installation​

Port Configuration 8 10/100/1000BASE-TX Gigabit Electrical Ports 4 1000BASE-SX/LX Gigabit Optical Ports (SFP Slots, Supports Single-mode/Multi-mode Switching)​

Transmission Rate 10Mbps/100Mbps/1000Mbps Auto-negotiation​

Network Protocols IEEE 802.3 IEEE 802.3u IEEE 802.3ab IEEE 802.3z IEEE 802.1Q (VLAN) IEEE 802.1w (RSTP) IEEE 802.1s (MSTP) IEEE 802.1p (QoS)​

Redundancy Protocols Support RSTP/MSTP Link Aggregation (LACP) Ring Redundancy (Self-healing Time ≤15ms) Dual-link Backup​

Switching Capacity 48Gbps​

Packet Forwarding Rate 35.7Mpps​

Buffer Capacity 16MB​

Management Functions Supports SNMP v1/v2c/v3 Web Management CLI Command Line Management Port Mirroring Flow Control QoS Priority Classification Port Security Storm Suppression​

Power Configuration Dual Redundant Power Input (Reverse Polarity Protection)​

Current Consumption Typical 250mA (24VDC) Maximum 380mA (24VDC)​

Size 140mm×110mm×55mm (Length×Width×Height)​

Weight 1.2kg​

Power Consumption Typical 6.0W Maximum 9.1W​

Certification Qualification CE UL CSA IEC 61010-1 IEC 61850-3 IEC 61508 SIL 2 EN 55032 Class A​

Compatible System GE PACSystems RX3i/RX7i/RX9i Controllers Proficy iFIX/SCADA Proficy Plant Applications Industrial Ethernet-compatible Devices​

Diagnostic Function Support Port Status LED Indication Link Fault Alarm Power Supply Fault Detection Ring Network Status Monitoring Traffic Statistics Module Self-diagnosis Cable Diagnosis​

Anti-interference Level Complies with EN 55032/EN 55035/EN 61000-6-2/EN 61000-6-4 Industrial EMC Standards​

MTBF (Mean Time Between Failures) ≥450,000 Hours​

PRODUCT PERFORMANCE​

Full Gigabit port combination design, 8 electrical ports adapt to short-distance equipment interconnection, 4 SFP optical ports support single-mode/multi-mode switching, meeting the needs of long-distance backbone transmission and cross-area network interconnection​

Dual redundant power input with reverse polarity protection ensures power supply continuity, avoids network interruption caused by single-point power failure, and improves system redundancy reliability​

Supports enhanced ring network redundancy protocol with self-healing time ≤15ms, combined with LACP link aggregation and dual-link backup functions, building a highly stable network architecture without single point of failure​

Switching capacity up to 48Gbps and packet forwarding rate of 35.7Mpps, with super large data throughput capacity, ensuring no congestion in concurrent communication of large-scale equipment and real-time transmission of control commands​

Integrates three management methods: SNMP v1/v2c/v3, Web management and CLI command line, supports port security, QoS priority classification and storm suppression, realizing refined network management and control​

Industrial-grade wide-temperature design, can operate stably in the temperature range of -40℃ to 75℃ and non-condensing humidity environment of 5%-95%, adapting to extreme industrial scenarios such as alpine, high temperature and high humidity​

IP40 protection level with high-strength metal shell, featuring dustproof, anti-vibration and anti-electromagnetic radiation performance, can be directly installed in industrial site cabinets or rails without additional protection​

Built-in comprehensive diagnostic functions such as cable diagnosis and port fault alarm, fault information is fed back in real time, facilitating rapid location of network problems and reducing operation and maintenance costs​

35mm standard DIN rail installation design, compact structure, easy to install and disassemble, adapting to the standardized cabinet layout of industrial sites, saving installation space​

Wide-range 18-36VDC power supply design, withstanding voltage fluctuations and transient sags, adapting to complex industrial power grid environments, ensuring continuous and stable operation of the device​

Seamlessly compatible with GE PACSystems full-series controllers and Proficy software platforms, can be quickly integrated into GE industrial automation ecosystem, reducing system integration complexity and costs​
