GE VMIVME1150 Real time controller module

Specific Parameters

Electrical Parameters
Processor: Motorola PowerPC 750FX processor, 500MHz clock speed
Memory Configuration: 128MB SDRAM (expandable to 256MB), 16MB Flash ROM (for firmware and configuration file storage)
Communication Interfaces: 2×10/100Mbps auto-negotiation Ethernet ports (RJ45, supporting TCP/IP, UDP protocols), 1×RS232 serial port (DB9 interface, supporting 9600-115200bps baud rate), 1×VME64x bus interface (32-bit/64-bit address width, maximum 160MB/s transmission rate)
Power Supply: +5V DC (±5%), +12V DC (±10%), -12V DC (±10%), powered by VME rack backplane
Power Consumption: ≤15W under normal operation, ≤18W under full load
Bus Protocol: Supports VMEbus Rev. C specification, compatible with VME64x extension standard, supports multi-master device bus arbitration (programmable priority)
Real-Time Clock: Built-in lithium battery-backed real-time clock (RTC), time accuracy ±1 minute/month (25℃ environment)
Environmental Parameters
Operating Temperature: 0°C to 60°C (non-condensing, preheating to 0°C required for startup below 0°C)
Storage Temperature: -40°C to 85°C
Relative Humidity: 5% to 95% (non-condensing, continuous operation for 72 hours at 90% humidity and 40°C without failure)
EMC Immunity: Complies with EN 61326-1 industrial standard, ESD protection ±15kV (air discharge), ±8kV (contact discharge), RF radiation protection ≤54dBμV/m (30MHz-1GHz)
Protection Class: IP20 (module itself, dependent on 3U VME rack overall protection)
Certification Standards: CE (EMC and safety), UL 508C (industrial control equipment), VMEbus Consortium certification
Mechanical Parameters
Dimensions: 160mm (L) × 100mm (W) × 233mm (H) (3U VME standard size, fits 3U VME rack slots)
Weight: Approximately 0.8kg
Mounting Method: Plug-in installation in 3U VME rack, complying with VMEbus mechanical specifications
Housing Material: Flame-retardant reinforced aluminum alloy (anodized surface treatment, UL 94 V-0 grade)
Indicators: Power Status (PWR, green, steady on for normal), Operation Status (RUN, green, 1Hz blinking for normal), Bus Status (VME, yellow, steady on for bus ready), Fault Status (ERR, red, steady on for fault)

Product Performance

The processor’s single-cycle instruction execution time is ≤2ns, supporting real-time operating systems (VxWorks, QNX) with task scheduling delay ≤1ms, meeting industrial-grade real-time control requirements. The VME64x bus interface supports 32-bit/64-bit data transmission with a maximum rate of 160MB/s, and the bus arbitration response time is ≤500ns during multi-master device concurrent access, avoiding bus congestion.

The Ethernet port has a data transmission delay of ≤10ms, supporting industrial-grade real-time communication protocols (e.g., Modbus TCP) to realize real-time data interaction with upper monitoring systems. Built-in hardware-level fault diagnosis circuit can monitor the status of key components such as processor, memory, bus interface and power supply, with diagnostic coverage ≥98%, and fault information is uploaded to monitoring nodes in real time via serial port or Ethernet.

The module has passed VMEbus Consortium compatibility testing, and can be seamlessly compatible with VME I/O modules and communication modules from different manufacturers, supporting hot swapping (requires rack support) with no shutdown required during replacement. Industrial-grade wide-temperature design and anti-EMC capability ensure stable operation in complex industrial environments, with Mean Time Between Failures (MTBF) ≥600,000 hours (MIL-HDBK-217F, 25℃ environment).
