GE VMIVME-7455 Multi protocol VMEbus communication module
Specific Parameters
Electrical Parameters
Communication Interfaces: 2 10/100/1000Base-TX Gigabit Ethernet ports (RJ45), 4 RS-232/422/485 serial ports (software-configurable)Supported Protocols: EtherNet/IP (Master/Slave), Modbus TCP/IP (Client/Server), PROFINET IO (Controller/Device), TCP/IP, UDP/IP, ICMPBus Interface: VMEbus Slave Interface, supporting A24/A32 address space, D16/D32 data width, 64KB VMEbus memory-mapped windowRedundancy: Supports Ethernet port link aggregation (LACP), device-level hot-standby redundancy, switching time ＜10msData Buffer: 8MB onboard RAM for data buffering, supporting over 1000 concurrent communication connectionsPower Supply Voltage: 24V DC, rated current 1.2APower Consumption: Typical power consumption 28W (under full load operation)Diagnostic Functions: Built-in port link detection, protocol anomaly alarm, power failure monitoring; diagnostic information output via VMEbus or EthernetStatus Indication: 1 bi-color LED (link/rate) per port, 1 system operation LED, 1 fault alarm LED
Environmental Parameters
Operating Temperature: -40℃ to +85℃ (non-condensing environment)Storage Temperature: -55℃ to +85℃Relative Humidity: 5% to 95% (non-condensing), compliant with IEC 60068-2-3 standardEMC Compliance: Compliant with IEC 61326-1 standard, common-mode interference immunity ≥120dB, differential-mode interference immunity ≥60dBProtection Rating: IP20 (module itself, requiring VME chassis for overall dust protection)Vibration Resistance: 10-500Hz frequency range, 1.5g acceleration (sine wave), 30 minutes of continuous testing per axisShock Resistance: 50g acceleration (11ms duration, compliant with IEC 60068-2-27 standard)
Mechanical Parameters
Overall Dimensions: Compliant with 6U VMEbus standard (160mm×233mm×30mm)Housing Material: Flame-retardant engineering plastic (UL94 V-0 grade), anti-static coating on surface, with RFI shielding functionWeight: Approximately 0.8kgMounting Method: Standard VMEbus slot mounting, compatible with 6U VME standard chassis (requiring 3U height space)Wiring Method: Ethernet ports support CAT5e/CAT6 twisted-pair cables (maximum transmission distance 100 meters); serial ports support shielded cables (maximum transmission distance 1200 meters in RS485 mode)
Product Performance
Communication compatibility is strong: It covers mainstream industrial Ethernet and serial protocols, and can directly connect to PLCs, DCS and terminal devices from different manufacturers. No additional protocol conversion modules are required, enabling seamless interconnection between VME systems and industrial networks.
Redundancy reliability is outstanding: Ethernet link aggregation and hot-standby redundancy design ensure uninterrupted communication; switching time ＜10ms meets the real-time requirements of industrial control, avoiding system shutdown caused by single-point faults.
Data transmission is efficient: Gigabit Ethernet ports combined with 8MB buffer allow a single module to carry over 1000 concurrent connections; data transmission delay ≤1ms (in local area network), meeting the needs of large-scale I/O data acquisition and control command issuance.
System integration is convenient: The standard VMEbus interface can be directly embedded into GE Fanuc VME series industrial computers, supporting real-time operating systems such as VxWorks and Linux. Protocol parameters and communication logic can be quickly configured through the configuration tools provided by the manufacturer.
Environmental adaptability is excellent: The wide temperature range of -40℃ to +85℃ covers extreme industrial scenarios; anti-vibration and anti-electromagnetic interference design ensures stable operation in high-interference environments such as power and metallurgy industries, without communication packet loss or protocol anomalies.
