GE VMIVME-5565-010000 332-015565-010000 P Industrial computer module

Specific Parameters

Core Configuration Parameters
CPU Model: 32-bit PowerPC 750FX processor
Operation Speed: 800MHz
Memory Capacity: 512MB DDR SDRAM (with ECC), 256MB Flash ROM
Bus Standard: VME64x (32-bit/64-bit data width, max 66MHz bus clock)
Storage Expansion: 1×CompactFlash slot (Type II)
Real-Time Clock: Built-in lithium battery backup, accuracy ±5ppm
Electrical Parameters
Supply Voltage: +5V DC (±5%), +12V DC (±10%), -12V DC (±10%)
Power Consumption: Typical 25W, Maximum 30W
Isolation Level: 2kVAC between I/O and system (1 minute)
Ground Resistance: ≤1Ω (protective grounding)
Surge Protection: Compliant with IEC 61000-4-5 (±2kV differential mode, ±4kV common mode)
Environmental & Mechanical Parameters
Operating Temperature: -40°C to 70°C
Storage Temperature: -55°C to 85°C
Relative Humidity: 5% to 95% (non-condensing, no dew)
Protection Class: IP20 (module itself)
Dimensions: 160mm (L) × 100mm (W) × 25mm (H) (VME standard card size)
Weight: Approximately 450g
Mounting Method: 3U VME standard rack mounting (compliant with IEEE 1101.1)
Communication Parameters
Built-in Interfaces: 2×10/100/1000Base-T Ethernet (RJ45), 2×RS232/RS485 serial ports (configurable), 1×VME bus interface
Expansion Interface: Supports I/O expansion modules via VME bus
Communication Protocols: TCP/IP, UDP, Modbus TCP, PROFIBUS DP (requires expansion module)

Product Performance

The module adopts PowerPC 750FX processor with 800MHz operation speed, combined with ECC-protected DDR SDRAM, ensuring accuracy and stability of data processing, and meeting the operation requirements of complex real-time control algorithms. The VME64x bus interface supports 64-bit data transmission with a maximum rate of 528MB/s, enabling high-speed data interaction between modules.

The rugged design allows stable operation in -40°C to 70°C wide temperature range, vibration resistance complies with MIL-STD-810H (10-2000Hz, 15g acceleration), shock resistance complies with MIL-STD-810H (50g, 11ms half-sine wave), adapting to harsh environments such as military and energy industries.

Built-in hardware self-diagnosis circuit can monitor CPU, memory, bus and power status, trigger alarm via interrupt signal when fault occurs, with Mean Time Between Failures (MTBF) ≥200,000 hours. It is fully compatible with GE VME series I/O modules and communication modules, supporting GE Proficy iFIX, CIMPLICITY and other configuration software, facilitating system integration and debugging.
