GE RS-FS-9001 362A1052P404 Flame detection and safety monitoring module
Specific Parameters
Electrical Parameters
Operating Voltage 24VDC (±10%), stable power supply over a wide rangePower Consumption Standby power consumption ≤5W, operating power consumption ≤10WDetection Spectrum Dual-spectrum coverage of infrared spectrum (700-2000nm) and ultraviolet spectrum (185-260nm)Detection Distance 0.5-15 meters, adapting to different combustion equipment sizesResponse Time ≤20ms, fast feedback of flameout signalInput Signals Supports input of burner operation status feedback signalsOutput Signals 2 channels of safety relay outputs (normally closed/normally open configurable), 1 channel of analog status output (4-20mA)Relay Contact Capacity 250VAC/5A, 30VDC/5AIsolation Level Electrical isolation between signal input and output, isolation voltage 1500VACProtection Features Built-in overvoltage protection, short circuit protection, reverse polarity protection, electromagnetic shielding protectionCertification Standards Complies with IEC 61508, EN 50156, UL 508 standards, certified to SIL 2
Mechanical Parameters
Overall Dimensions 140mm×110mm×60mm, compact design suitable for industrial control cabinetsWeight Approximately 0.6kg, lightweight facilitating installation and deploymentMounting Method 35mm standard DIN rail mounting or panel mountingHousing Material Industrial-grade high-strength flame-retardant ABS shell with impact resistance and dustproof performanceConnection Method Plug-in spring terminals, compatible with 0.5-1.5mm² shielded cablesProtection Rating IP54, dustproof and waterproof for on-site installation environmentsStatus Indication Equipped with power (green), operation (yellow), normal flame (green), fault (red) LED indicators
Environmental Parameters
Operating Temperature -40℃ to 70℃, no performance derating over the entire temperature rangeStorage Temperature -55℃ to 85℃, meeting extreme storage and transportation requirementsRelative Humidity 5% to 95% (non-condensing), adapting to high-humidity industrial scenariosVibration Resistance Complies with IEC 60068-2-6 standard, 2g acceleration at 5Hz-500Hz frequency rangeShock Resistance Complies with IEC 60068-2-27 standard, 15g acceleration (11ms duration)EMC Compliance Complies with EN 55014-1, EN 61000 standards, meeting anti-external electromagnetic interference requirements
Product Performance
High detection accuracy: Dual-spectrum complementary detection technology, 100% flame identification accuracy, eliminating false alarms and missed alarmsCompliant safety level: SIL 2 certification meets the safety requirements of industrial combustion systems, diagnostic coverage ≥99%Fast response speed: ≤20ms flameout response time ensures rapid execution of emergency interlock actionsStrong environmental adaptability: Wide temperature operation + IP54 protection, tolerating harsh working conditions such as high temperature, dust and humidityExcellent anti-interference capability: Electromagnetic shielding + signal filtering technology resists electromagnetic interference and false signals in industrial sitesComprehensive self-diagnostic functions: Real-time monitoring of module circuits and optical component status, instant feedback of fault informationFlexible installation and configuration: Multiple installation methods + configurable output contacts, adapting to different combustion equipment needsHigh operational stability: Industrial-grade component selection, Mean Time Between Failures (MTBF) ≥500,000 hours
