GE RS-FS-9001 362A1052P004 flame detector

Specific Parameters

Detection Range: Approximately 9 meters (30 feet)
Detection Type: Ultraviolet and infrared
Operating Temperature Range: – 40°C to + 85°C
Storage Temperature Range: – 40°C to + 85°C
Humidity Range: 5% to 95% (non – condensing)
Protection Level: IP66
Output Signal: 4 – 20mA current signal
Power Supply Voltage: 24V DC (±10%)
Response Time: <50ms (typical value)
Interface: 3/4 – inch NPT stainless – steel threaded interface
Weight: Approximately 3 – 5kg (including installation accessories)
Certifications: ETL, ATEX, IECEx, Class I Division 2
Connection Method: Cable connection
Structure: Modular design, easy to install and maintain
Materials: High – temperature – resistant and corrosion – resistant materials
Self – Diagnostic Function: Available, can automatically detect faults and provide alarm information
Water – Cooling Requirements: External water – cooling coil is required, with a flow rate of ≥1.0 GPM (3.8 LPM) and a water temperature of 10°C – 57°C
Air – Cooling Requirements: Forced air velocity of ≥1.5 m/s (when the ambient temperature is ≤60°C) or pressurized air (less than 25 psi)
Cable Specification: Shielded twisted – pair (18 AWG), with a maximum length of 1000 meters
Polarity: White is positive, black is negative / signal ground, and reverse connection will not damage the device

Product Performance

High – Sensitivity Detection: Relying on ultraviolet and infrared detection technologies, it is highly sensitive to flames. It can quickly identify weak or strong flame signals, greatly improving the timeliness of fire early – warning and effectively reducing fire risks.
Strong Anti – Interference Ability: Its special design enables it to effectively resist external factors such as electromagnetic interference and light interference, reducing false alarms. It ensures reliable operation and accurate detection results even in complex industrial electromagnetic environments and under changing lighting conditions.
High – Temperature Resistance Performance: Made of high – temperature – resistant materials, it can work stably in high – temperature environments. It meets the flame monitoring requirements around high – temperature equipment such as gas turbines, industrial boilers, and heating furnaces, and will not be affected by high – temperature environments in terms of detection performance.
Fast Response Characteristic: With a response time of less than 50ms, once a flame is detected, it can quickly issue an alarm or control signal, winning precious time for timely fire – fighting or safety protection measures. It is suitable for industrial scenarios with extremely high requirements for the timeliness of fire response.
Long Life and Low Maintenance: The welded structure and sealed design prevent disassembly, ensuring long – term reliability. The modular design is convenient for installation and maintenance, reducing maintenance workload and costs and improving equipment efficiency and stability.
Wide Environmental Adaptability: With an operating temperature range from – 40°C to + 85°C, a humidity range of 5% to 95% (non – condensing), and a protection level of IP66, it can work normally in harsh industrial environments such as high – temperature, humid, and dusty conditions, with a wide range of applicable scenarios.
Compliance with Safety Standards: It has obtained multiple certifications such as ETL, ATEX, IECEx, and Class I Division 2, meeting strict safety standards. It can be used for flame monitoring in hazardous areas to ensure safe production.
