GE IS420YDOAS1B Input/output module

GE IS420YDOAS1B Input/output module

Specific Parameters

• Electrical ParametersSupply Voltage: 24V DC (industrial standard control power supply)Input Channels: 4 analog inputs, 2 digital inputsOutput Channels: 2 analog outputs, 2 digital outputsSignal Types: Analog inputs support 4-20mA current signals, ±10V voltage signals; analog outputs support 4-20mA current signals; digital I/O are 24V DC discrete signalsAccuracy Indicators: Non-linearity ≤0.05%, repeatability ≤0.02%Isolation Level: Electrical isolation between channels and between channels and power supply, isolation voltage ≥1500V DC (1min withstand voltage test)Communication Interfaces: Supports RS-232/485, Modbus protocol, equipped with IONet interface and RJ45 connection terminalsDiagnostic Functions: Supports channel short circuit and open circuit detection; power-on self-test covers memory, communication ports and hardware circuits; fault status is uploaded in real time
• Environmental ParametersOperating Temperature: -40°C to 70°C (non-condensing environment)Storage Temperature: -55°C to 85°CRelative Humidity: 5% to 95% (non-condensing, no persistent dew)Vibration Resistance: 10-500Hz frequency range, 1.5g acceleration (compliant with IEC 60068-2-6 standard)Shock Resistance: 30g acceleration, 11ms duration (compliant with IEC 60068-2-27 standard)Protection Class: IP65 (module body protection)
• Mechanical ParametersDimensions: 160mm (L) × 80mm (W) × 35mm (H) (including connectors)Weight: Approximately 0.7kgMounting Method: Compatible with Mark VIe control system rack installation, supporting standard 35mm DIN rail fixingHousing Material: Flame-retardant reinforced engineering plastic (UL 94 V-0 grade, chemical corrosion resistant)Indicators: Power status (green steady on = normal), operation status (green blinking = working), fault alarm (red steady on = abnormal)

Product Performance

Excellent signal processing accuracy: Analog channels with ≤0.05% non-linearity and ≤0.02% repeatability ensure accurate acquisition and output control of process variables such as temperature and pressure, adapting to high-precision regulation scenarios. Hybrid channel design enables integrated processing of digital and analog signals, reducing the number of system modules and improving integration efficiency.

Comprehensive diagnostic coverage: Combined power-on self-test and real-time channel monitoring, fault response time ≤100ms, and alarm information is uploaded synchronously via communication interface, significantly reducing maintenance troubleshooting time. Industrial-grade component selection and wide-temperature design ensure stability with Mean Time Between Failures (MTBF) ≥1.0×10⁶ hours, enabling continuous operation in high-temperature, strong electromagnetic interference industrial environments.

Strong communication compatibility: Supports multiple industrial protocols for seamless connection with control systems, signal transmission delay ≤20ms, meeting the command response requirements of real-time control scenarios.
