GE IS420UCSBH1A communication interface module

Supply Voltage: 24V DC (±10%)

Rated Power Consumption: ≤3.8W

Power Isolation: 2500Vrms (for 1 minute continuously, power and signal terminals)

Supported Protocols: EtherNet/IP, Modbus TCP, GE Profinet

Communication Rate: 100Mbps (full-duplex, EtherNet/IP/Profinet), 10/100Mbps auto-negotiation (Modbus TCP)

Maximum Connections: 16 (EtherNet/IP slave devices), 8 (Modbus TCP clients)

Data Transmission Delay: ≤5ms (bidirectional transmission of control commands)

Signal Input Type: Differential signal/single-ended signal (configurable)

Signal Filter Level: 3 levels programmable (0.5ms-50ms)

Data Buffer Capacity: 8KB (process data buffer)

Operating Temperature Range: -40°C to +70°C

Storage Temperature Range: -40°C to +85°C

Relative Humidity: 5% to 95% (non-condensing, when temperature ≤40°C)

Protection Class: IP20 (module body), IP40 (connector interface)

Mounting Type: 35mm standard DIN rail mounting

Dimensions: 135mm×92mm×48mm

Weight: Approximately 0.45kg

Connector Type: Plug-in terminal (2.5mm pitch, gold-plated contacts)

Multi-Protocol Compatible Transmission: Simultaneously supports three mainstream industrial protocols (EtherNet/IP, Modbus TCP, GE Profinet), enabling cross-protocol device interconnection without additional gateways, reducing system integration complexity, with data transmission bit error rate ≤10⁻⁹.
High Anti-Interference Ability: Adopts differential signal transmission and electromagnetic shielding shell, combined with 2500Vrms power isolation design, which can resist surges, electromagnetic radiation, and grounding interference in industrial sites, ensuring stable signal transmission.
Stable Operation in Wide Temperature Range: Passes full temperature range testing from -40°C to +70°C, no start-up delay in low-temperature environments, and parameter drift ≤0.3% during 72-hour continuous operation at high temperatures, adapting to outdoor and harsh industrial scenarios.
Real-Time Data Interaction: 100Mbps full-duplex communication rate and ≤5ms transmission delay enable real-time synchronization of control commands and on-site data, meeting high real-time control needs (such as motor speed regulation, precise valve adjustment).
Intelligent Fault Diagnosis: Real-time monitors communication link status, power voltage, and signal integrity, feeds back fault types (such as communication interruption, power overvoltage) through LED indicators and system alarm signals, with fault location accuracy reaching the channel level.
