GE IS230PCAAH1B Analog input/output (I/O) module

GE IS230PCAAH1B Analog input/output (I/O) module

Specific Parameters

Brand GE (General Electric), Product Series GE Mark VIe Series

Product Type Core Analog Input/Output (I/O) Module, Industrial Control Module, GE Original Spare Part

Model GE IS230PCAAH1B

Country of Origin United States (Produced by GE original factory)

Compatible Devices GE Mark VIe Series Distributed Control System, Speedtronic Turbine Control System, TCAS/TCAT Series Terminal Boards, JGPA Boards, Mark VIe Ethernet I/O Modules

Core Functions Analog Signal Acquisition and Output, LVDT Excitation, Servo Coil Control, Signal Distribution and Processing, Fault Diagnosis

Number of Input Channels 25 Analog Input Channels

Input Signal Type Thermocouple Input, 4-20mA Current Loop Input, Seismic Signal Input, LVDT Excitation and Input, Pulse Rate Input

Output Signal Type 4-20mA Current Signal, Servo Coil Output

Analog Input Accuracy ±0.50% for 0-10V DC Input, ±1.00% for LVDT Excitation Monitor Input

Output Accuracy ±3.50% for Servo Driver Output

Power Supply Voltage 28VDC±5%

Operating Temperature Range -30℃ to 65℃

Storage Temperature Range -40℃ to 85℃

Relative Humidity 5% to 95%, Non-Condensing

Protection Class IP20

Physical Dimensions 33.02cm×17.8cm (Height×Width)

Physical Weight Approximately 2.5kg

Mounting Method Standard Industrial Rack Mounting

Technology Surface-Mount Technology

Communication Interfaces 2 RJ45 Ethernet Interfaces

Terminal Type 120 Euro-Style Box Terminals

Configuration Software Supports GE ControlST Software (Version Requirements Must Be Met)

Applicable Systems Simplex, Dual, and TMR (Triple Modular Redundancy) Systems

Protection Functions Overcurrent, Overvoltage Protection, Fault Diagnosis and Alarm Function

Product Material Industrial-Grade Reinforced Housing, High-Temperature Resistant Insulation Material

Customizable No

Certification Standards Complies with CE, IEC Relevant Certification Standards

Warranty Period 12 Months

Product Performance

GE IS230PCAAH1B is an original GE device with strong adaptability, which can be seamlessly integrated into GE Mark VIe Series control systems, with convenient installation and maintenance. A single TCAT terminal board can distribute signal inputs to 1-3 associated modules, no need to replace internal circuit boards separately, and the overall reliability is outstanding. The product has high signal processing accuracy and strong adaptability to various signal types, which can meet the multi-type signal acquisition and control needs of key equipment such as gas turbines. Adopting surface-mount technology, it has a compact and solid structure, and its anti-electromagnetic interference and anti-vibration capabilities meet industrial standards. The product has complete fault diagnosis functions, can quickly locate operation abnormalities, supports system firmware upgrade, can operate continuously and stably in harsh industrial environments, effectively improves the operation efficiency and safety of the turbine control system, and reduces operation and maintenance costs.
