GE IS215WEPAH2BB Input/Output (I/O) Module
Specific Parameters
- Electrical ParametersSupply Voltage: 24V DC (supporting 19.2-30V DC wide-range input)Analog Inputs: 8 channels, supporting 4-20mA/0-10V signals, 16-bit resolution, ±0.1% accuracyDigital Outputs: 8 channels, 24V DC relay contacts, maximum load 2A/250V ACCommunication Interfaces: 2 IONet fiber optic interfaces (100Mbps), 1 UDP Ethernet interface (10/100Mbps)Isolation Level: Isolation voltage ≥1500V DC between power and signal circuits, insulation resistance ≥200MΩ (500V DC)Protection Functions: Overcurrent protection (3A current limiting), overvoltage protection (36V DC threshold), reverse polarity protection
- Environmental ParametersOperating Temperature: -40°C to 70°C (non-condensing)Storage Temperature: -55°C to 85°CRelative Humidity: 5% to 95% (non-condensing)Vibration Resistance: 10-500Hz, 1.5g acceleration (IEC 60068-2-6 standard)Shock Resistance: 30g acceleration, 11ms duration (IEC 60068-2-27 standard)
- Mechanical ParametersDimensions: 100mm (L) × 80mm (W) × 20mm (H)Weight: Approximately 0.5kgMounting Method: Standard DIN rail mounting, supporting hot-swappingHousing Material: Flame-retardant reinforced plastic (UL 94 V-0 grade)Indicators: Power (PWR, green), Operation (RUN, green blinking), Communication (COM, orange blinking), Fault (ERR, red)
Product Performance
The module features a signal processing cycle ≤5ms, supporting three selectable frame rates (10ms, 20ms, 40ms) to meet fast control loop requirements. With a Triple Modular Redundancy (TMR) design, it automatically switches to the standby channel in case of single-channel failure, ensuring continuous operation with a switching time <20ms. Built-in intelligent diagnostics monitor channel short circuits, open circuits, and communication anomalies in real time, achieving a diagnostic coverage rate ≥99%, with fault information uploaded to the master control system via the bus. The module has a Mean Time Between Failures (MTBF) ≥1,500,000 hours (MIL-HDBK-217F standard) and supports online configuration download and firmware upgrades without affecting production during maintenance.
