GE IC752SPL013-BA EX2100 Operation panel module
Specific Parameters
Electrical Parameters
Power Supply Voltage: 24V DCChannel Configuration: 8-channel signal processing capability, supporting analog and digital signal accessInput Signal Types: Compatible with 4-20mA current signal, 0-1VDC/0-5VDC voltage signal, adaptable to RTD Pt100 and J, K type thermocouplesOutput Signal Range: 0.6V DC or 0-10V DCCommunication Protocols: Supports Modbus RTU, DNP3, IEC 61850 and RS485 serial communicationDiagnostic Bus: 2 Mbps HDLC diagnostic bus for real-time fault information transmissionStorage Configuration: 8 KB NVRAM for parameter and fault record storageResolution: 16-bit signal conversion resolution to ensure data acquisition accuracyStatus Indication: Multi-color LED indicators for power, communication, operation and fault status feedback
Environmental Parameters
Operating Temperature: -40℃ to +70℃ (non-condensing environment)Storage Temperature: -40℃ to +85℃Relative Humidity: 5% to 95% (non-condensing)EMC Compliance: Conforms to industrial electromagnetic interference protection standards, with common-mode interference resistance adapting to complex electromagnetic environments in power systemsProtection Rating: IP20 (module itself, requiring control cabinet for overall protection)
Mechanical Parameters
Overall Dimensions: 166mm×112mm×36mmHousing Material: Flame-retardant engineering plastic (UL94 V-0 grade) with RFI shielding functionWeight: Approximately 375gMounting Method: 35mm standard DIN rail mounting, supporting panel fixingWiring Method: Adaptable to industrial terminal wiring, supporting shielded cable access, maximum signal transmission distance ≤100 metersFront Panel Configuration: Integrated operation buttons and LCD display window, including parameter adjustment and confirmation function keys
Product Performance
Signal processing accuracy is high: 16-bit conversion resolution combined with factory calibration ensures that the acquisition error of key parameters such as voltage and temperature is controlled within the industrial-grade allowable range, providing accurate data support for excitation regulation.
Communication compatibility is strong: Supports mainstream communication protocols in power systems, enabling seamless connection with DCS systems, SCADA platforms and third-party excitation equipment for remote monitoring and data upload without additional protocol conversion modules.
Operation reliability is outstanding: The wide temperature range of -40℃ to +70℃ covers high and low temperature industrial scenarios; anti-electromagnetic interference design adapts to the strong electromagnetic environment near generators; 24V DC stable power supply ensures continuous operation without interruption.
Maintenance convenience is excellent: HDLC diagnostic bus transmits fault information in real time; LED indicators intuitively feed back operation status; NVRAM saves parameters after power failure to avoid configuration loss after restart, reducing fault troubleshooting and recovery time.
Operation adaptability is flexible: 8-channel signal interface is compatible with various sensors and actuators; supports user-defined parameter thresholds and control logic, adapting to excitation requirements of generators with different power levels.
