GE IC695CPE330 Central Processing Unit (CPU) module
Specific Parameters
Processor Type 1GHz Dual-Core Microprocessor
User Memory 64MB RAM; 64MB Non-volatile Flash User Memory
Boolean Execution Speed 0.04µs per Instruction
Program Block Support Up to 512 Program Blocks, Each Up to 128KB
Reference Table Sizes 32Kbits Each for Discrete %I and %Q; Up to 32Kwords Each for Analog %AI and %AQ
Communication Interfaces 2 10/100/1000Mbps Auto-Sensing Gigabit Ethernet Ports (RJ45); 1 USB 2.0 Type A Port
Communication Protocols Supports SRTP, EGD, Modbus TCP, PROFINET, OPC UA, IEC 61850, etc.
Operating Voltage 5VDC (Backplane); External 24VDC (Optional)
Operating Current Maximum 1.2A at 5VDC; 5mA at 24VDC (Isolated)
Power Dissipation Maximum 12W
Operating Temperature Range 0℃ to 60℃
Storage Temperature Range -40℃ to 85℃
Relative Humidity 5% to 95%, Non-Condensing
I/O Expansion Capacity Supports Up to 32K Discrete I/O Points and 32K Word Analog I/O Points; Supports Up to 8 Local Racks
Data Format IEEE 32-bit Floating Point; 16-bit Integer in a 32-bit Field
Mounting Type Standard 35mm DIN (TS35) Rail Mounting
Overall Dimensions 165mm×165mm×100mm
Weight 0.66kg
Certification Standards Complies with CE, UL, cUL, ATEX, IECEx Certifications, RoHS Compliant
Memory Retention Optional IC695ACC402 Energy Pack Writes User Memory to Non-volatile Storage on System Power Loss
Simultaneous Connections Supports Up to 48 SRTP Server Connections and Up to 16 Modbus TCP Server Connections
Product Performance
High-Speed Computing Performance: Adopts 1GHz dual-core microprocessor with Boolean execution speed of 0.04µs per instruction, supports firmware-based floating-point arithmetic, can quickly complete complex logic operations, mathematical operations and multi-task processing without delay or lag, meeting the real-time requirements of medium and large-scale industrial automation control.
Large-Capacity Configurable Storage Performance: Equipped with 64MB RAM and 64MB non-volatile flash user memory, can configure register, analog and other memory blocks according to needs, can store complex control programs and a large amount of operation data, meeting the program development and data processing needs of medium and large-scale control systems.
High Expansion Performance: Supports up to 32K discrete I/O points and 32K word analog I/O point expansions, can connect up to 8 local racks, compatible with various I/O modules and communication modules of the GE PACSystems RX3i series, and can flexibly expand system functions without replacing the CPU module, adapting to medium and large-scale automation control systems of different scales.
Multi-Protocol High-Speed Communication Performance: Built-in 2 gigabit Ethernet ports and 1 USB 2.0 Type A port, supports multiple communication protocols such as SRTP, EGD and Modbus TCP, supports network redundancy and independent IP address configuration, which can realize high-speed data transmission, seamlessly connect to SCADA, HMI and other industrial automation equipment, realizing real-time data interaction and centralized management and control.
Stable Operation Performance: Complies with industrial-grade design standards and multiple certifications, the metal housing has excellent anti-interference ability, can operate stably in the operating temperature range of 0℃ to 60℃, adapts to various harsh industrial on-site environments, has a long mean time between failures, and operates without faults for a long time.
Easy Maintenance Performance: Adopts modular design, supports online maintenance, remote debugging and fault diagnosis, can quickly locate fault points through local or remote methods, the modular structure is easy to disassemble and replace, equipped with multi-color LED status indicators to real-time feedback the equipment operation status, shortening maintenance time and reducing operation and maintenance costs.
Flexible Programming Performance: Compatible with IEC 61131-3 standard, supports multiple programming languages such as Ladder Diagram, Function Block Diagram, Structured Text and C language, compatible with Proficy Machine Edition engineering software, facilitating users to develop, debug and modify programs, adapting to different users’ programming habits.
High Reliability Performance: Supports program password protection, firmware secure boot and watchdog timer, has a comprehensive diagnostic buffer that can record the last 10,000 events, and the optional energy pack ensures that data is not lost when the power is cut off, meeting the reliability requirements of critical industrial control scenarios.
