GE IC660BBA104 Simulated hybrid module group

Specific parameters
I/O points: There are a total of 6 I/O points, including 4 input points and 2 output points.
Input/output range: The input range is 4-20mA, and the output range is also 4-20mA.
Accuracy: The input accuracy is 0.1% of the full-scale reading, and the output accuracy is 0.15% of the full-scale reading.
Resolution: Input resolution is 1 μ A, output resolution is 6 μ A.
Power supply: The rated voltage is 115VAC/125VDC, and the operating voltage range is 93-132VAC/105-145VDC.
Physical dimensions: approximately 8.83 inches (22.44 centimeters) x 3.34 inches (8.48 centimeters) x 3.91 inches (9.93 centimeters).
Weight: 4 pounds (approximately 1.8 kilograms).
Isolation characteristics: It has block isolation of 1500 volts, group isolation of 1500 volts, and input channel isolation of 1500 volts.

Product Performance
Accurate and reliable: It can provide accurate current sources to ensure the accuracy of analog signal input and output. The full-scale reading accuracy can reach 0.1% at 25 degrees Celsius.
Powerful diagnostic function: Each input channel is designed with a single diagnosis, such as low/out of range, high/low alarm, and open line detection; The output channel can also perform internal diagnostics, such as low distance, out of range, and feedback errors.
Flexible configuration: Users can configure the conversion time, ranging from 16.6ms to 400ms, and choose the appropriate conversion time according to actual needs to balance noise suppression level and input resolution.
Strong compatibility: Compatible with PCIM modules, QBIM modules, and all GE Genius bus controllers, making it easy to integrate into existing systems.
