GE IC3600SAHC1 – Industrial Control Module, High-Performance Design for Reliable Operation
The GE IC3600SAHC1 is a high-quality board designed for use in GE’s Mark I and II turbine control systems. It offers reliable performance and durability in industrial environments.
Model:IC3600SAHC1
Manufacturer:General Electric
Compatibility:GE Mark I-II Turbine Control Systems
Features:Resistors, Diodes, Advanced Circuitry
Dimensions:Standard PCB Size
Weight:Lightweight Design
This board is specifically manufactured for integration within GE Mark I-II turbine control systems. With its robust design, the IC3600SAHC1 board offers unparalleled reliability and performance.
Featuring a series of resistors, one large resistor is positioned on the lower edge of the PCB. This resistor is brown with bands that are orange, white, red, and gold, indicating its specific resistance value. Additionally, six more resistors are placed on the left side of the board, each with their own color-coded banding representing distinct resistance values. These resistors are arranged in a line, contributing to the board’s efficient power management capabilities.
On the right side of the board, there is a cluster of small blue diodes, enhancing the board’s overall functionality by providing protection against voltage surges and other electrical disturbances.
Crafted with precision and engineered for durability, the IC3600SAHC1 board is an essential component for any turbine control system. Its compatibility with GE Mark I-II systems ensures seamless integration and operation.
