GE Fanuc 3AL78821BAAH01 Universal Module

GE Fanuc 3AL78821BAAH01 Universal Module

    This high-performance universal module is designed for integration into industrial control systems. It supports various input types including thermocouples, RTDs, strain gauges, voltage, and current inputs. The module features automatic calibration, error checking, and configurable alarms.

Manufacturer:General Electric

Model:3AL78821BAAH01

Channels:8-channel

Type:Analog Input Module

Speed:High-speed

Input Range:Variable

Filter Frequencies:6 hardware configurable frequencies

Self-Diagnostics:Yes

Short Circuit Detection:For RTD

Alarm Detection:High, High-High, Low, Low-Low

Calibration:Automatic

Terminal Block Detection:Yes

Operating Temperature:Celsius or Fahrenheit display

Software Configuration:Yes

Interface Bus:High-speed RX3i PCI bus

    This advanced 8-channel universal analog input module from GE Fanuc is the first to operate at high speed on the RX3i PCI bus. It replaces third-party modules like thermocouples, strain gauges, RTDs, voltage, and current modules. Featuring software configuration without the need for module jumper settings, it supports up to six hardware analog-to-digital filter frequencies per channel, allowing independent selection of channels. Automatic calibration based on filter frequency ensures precision, while comprehensive error checking mechanisms provide reliable performance. The module also includes short-circuit detection for RTDs, user-defined range scaling, and high/low alarm detection with fault reporting support within logic programs. Each channel has configurable software filters and interrupt capabilities for alarms and faults. Terminal block insertion or removal detection enhances system safety and reliability.
