GE DS200TCPDG1BEC Industrial grade distribution board
Specific Parameters
Brand GE (American Brand)
Product Series GE Mark V Series Turbine Control Accessories
Product Type Industrial-Grade Power Distribution Board
Model DS200TCPDG1BEC
Compatible System GE Mark V Turbine Control System, Industrial Automation Power Distribution System
Supply Voltage 24VDC
Rated Current 20A
Hardware Configuration 8 toggle switches, 36 fuses, 4 signal wire terminals, 1 10-pin connector
Status Indication 36 green LED indicators (corresponding to fuse working status)
Operating Temperature Range -40℃ to +70℃
Protection Features Dew point condensation resistance, anodized aluminum housing against shock and vibration
Physical Dimensions 118mm×105mm×48mm
Physical Weight 0.3kg
PCB Coating Standard coating, functional version B/E, artwork version C
Installation Method Embedded installation, compatible with turbine control system cabinet
Certification Standard Compliant with CE, ISO standards
Origin United States
Product Performance
The dedicated power distribution architecture enables precise power distribution. 36 fuses independently protect corresponding circuits, and combined with LED status indicators, fuse faults can be quickly located, and working status can be judged without disassembly.
The anodized aluminum housing has excellent shock and vibration resistance. The dew point condensation resistance design can adapt to humid and cold environments, ensuring stable operation under complex working conditions of turbine operation.
Standardized size and interface design can be seamlessly integrated into the GE Mark V series turbine control system, completing installation without additional adaptation and greatly shortening the commissioning cycle.
24VDC stable power supply and 20A rated current configuration can meet the power requirements of turbine auxiliary equipment, sensors and control modules, with fast overload protection response.
The independent fuse mounting can adopts a rotary opening structure, making fuse replacement convenient. The top-connected design avoids component loss and improves maintenance efficiency.
It has complete EMC anti-interference capability, which can resist electromagnetic interference in industrial fields, ensure that power distribution accuracy is not affected by the external environment, and guarantee stable operation of backend equipment.
PCB standard coating treatment improves moisture and corrosion resistance, extends product service life, and adapts to industrial power scenarios with long-term continuous operation.
8 toggle switches can flexibly configure power distribution circuits, adapt to the power requirements of different turbine operation modes, with outstanding compatibility and flexibility.
